CSN Multiformat Reader (MIFARE, classic, Felica ICLASS)

New CSN ​​SELECT smart readers

The most powerful Smart Readers are the AY-K/M/H/L/R6255 series from ROSSLARE, Multi-format for 13.56 MHz credentials, feature multi-format output and excellent read range and use in any environment.

Main features of CSN readers:

CSN reads the following formats:

• MIFARE Ultralight / Ultralight C.
• MIFARE Classic.
• MIFARE Plus S / Plus X
• MIFARE DESFire EV1.
• ISO 14443A / ISO 18092 (NFCIP-1)
• ISO 14443B
• ISO 15693/Felica/Topaz/iClass
• NFC (ask for device compatibility)

Compatible with:

• AC-015
• AC-115
• AC-215
• AC-215IPL
• AC-225IPL
• AC-425IPL
• AC-825IP

• Reading range 3 cm.
• Wiegand 26-bit output.
• Requires 5 22 gauge wires (120m max).
• Power supply 12 Vdc, 120 mA.
• Dimensions: 80.5 x 40.5 x 14.7 mm.
• Weight 77 g.
