47" Series 21 Turret with 300 LEDs, Front: Red/White, Blue/White, Rear: Red/Amber, Blue/Amber

Name: 47" Series 21 Turret with 300 LEDs, Front: Red/White, Blue/White, Rear: Red/Amber, Blue/Amber
Brand: COLOMBIATEL TELECOMUNICACIONES
SKU: 21-31952-C
Availability: OutOfStock

$0 COP

~~$0 COP~~ $0 COP

Sale Sold out

Shipping calculated at checkout.

Quantity

47" Series 21 Turret with 300 LEDs, Front: Red/White, Blue/White, Rear: Red/Amber, Blue/Amber

21TR™ PLUS / 21IF series

CLASS SAE I

The 21TR™ Plus and 21IF are LED light bars that offer superior off-angle and directional performance. This economical yet advanced light bar offers standard features that provide the brightest entry-level light bar on the market.

The 21TR™ Plus features a deluxe center controller, 40+ flash patterns, NarrowStik™, takedown and alley flashing, cruise lights, and an available multi-color feature. The 21IF is a standalone flashing LED light bar that features takedown and alley flashing, independent flashing light heads, and user-selectable flash patterns. Each light head has a clear lens, takedown light, alley flashing, and a dimming mode.

specs

Voltage 12 Vdc

Flash patterns: 40

Approval: SAE Class I, SAE J845, SAE J595,

CALIFORNIA TITLE 13, NFPA, R10, R65, CISPR 25.

Height 2.1 '

Length: 47 '

Depth 12.3 '

15' cable with driver's side exit

Adjustable mounting legs (excluding 22' light bar which includes a permanent mounting kit)

5-year warranty

Configuration:

18 modules with a total of 300 LEDs:

5 modules of 18 LEDs, 3 front and 2 corner, red/white

5 modules of 18 LEDs, 3 front and 2 corner, blue/white

6 modules of 18 LEDs, 3 rear red/amber and 3 rear blue/amber

2 modules of 6 LEDs placed at the side ends (streets) in red white and blue white.

To specify:

Turret based on LED technology and 47” Torus optics with a one-piece aluminum base, includes lower polycarbonate domes in three sections in clear color and upper polycarbonate domes in three sections, the driver's side section in red, the middle section in clear color and the passenger side section in blue, the upper domes are held by means of stainless steel clips to facilitate maintenance of the turret. The turret has 300 dual color LEDs and the interior LED modules are distributed in the turret as follows

4 dual-color corner modules with 18 LEDs each, 2 on the driver's side, red/white, and two on the passenger side, blue/white.

2 dual-color alley modules with 6 LEDs each, 1 on the driver's side, red/white, and one on the passenger side, blue/white (programmable to work with white corner lights)

6 dual-color front modules with 18 LEDs each, 3 on the driver's side in red/white and 3 on the passenger side in blue/white with white penetration light operation programmed in the 6 front modules.

6 dual-color rear modules with 18 LEDs each, 3 on the driver's side in red/amber and 3 on the passenger side in blue/amber with amber traffic director operation programmable in all 6 modules.

Additional Features

360° programmable scene light

360° red/blue light

Dual Color Traffic Director

5 Year Warranty, Compliant with SAE CLASS I, SAE J845, SAE J595, CALIFORNIA TITLE 13, NFPA, R10, R65, CISPR 25, 40+ Flash Patterns, Polycarbonate Lens & Waterproof Housing, 12 Vdc
