Electrical Sheet c880 / Fire Resistant / UL®

Electrical Sheet c880 / Fire Resistant / UL®

This electric lock was designed for applications requiring high security without sacrificing aesthetics, and is locked in the event of a failure. It can work in conjunction with access control equipment such as proximity readers, keypads, biometric readers, etc., or it can operate independently, as it features a 12 V DC input for remote activation.

Recommended for applications on metal or wooden doors, in schools, hospitals, public, private and government buildings, museums, universities, etc.

• C880EU RX D LR E6268
• Closed in case of failure.
• Stainless steel.
• Conventional cylinder
• 3-1/2' Dia –3-1/2' Dia. stepped rose
• Satin finish.
• Tested to over 4 million cycles.
• Voltage: 12 Vdc, 500mA (not included).
• 2-year warranty on electrical parts.
• Warranty on mechanical parts for up to 10 years.
• SYSRMTXT backup source is recommended.
• Certifications: UL, BHMA, ANSI (A156.2),

NOTE: It is recommended to use Electric Hinge 9520 for correct installation.


*Product on Request.
