• The LED “blinks” when the unit is polled (communicating with the fire panel) and remains solid in alarm.
• Sleek, low-profile, and stylish design
• Remote test function from the panel
• Removable cover and insect-resistant screen for easy cleaning in the field
• Addressing by rotary switches
• FlashScan Communication Protocol
• Black color exchange option ( CK300-BL )
• Requires separate purchase of base ( B300-6 )

• Power supply: 15 to 32 Vdc
• Operating current at 24 Vdc: 200 μA
• Maximum current at 24 Vdc: 4.5 mA
• Operating temperature: 0°C to 50°C
• Operating humidity range: 10% to 93% non-condensing.
• Weight: 95 g
• Dimension: 51mm height and 15.6cm diameter with B300-6 base

The FSP-951 Series detector sensitivity can be programmed in the control panel software. Sensitivity is continuously monitored and reported back to the panel. Point ID capability allows the address of each detector to be set using rotary decimal address switches, providing the exact location of the detector for targeted maintenance when chamber contamination reaches an unacceptable level.
