HIKVISION
Ultra-fast Facial Recognition WiFi Terminal (IP65) / Up to 1.5 meters reading / Supports P2P Hik-Connect / 3,000 Users / QR and Video Intercom (low-noise environments)
Ultra-fast Facial Recognition WiFi Terminal (IP65) / Up to 1.5 meters reading / Supports P2P Hik-Connect / 3,000 Users / QR and Video Intercom (low-noise environments)
Couldn't load pickup availability
Ultra-fast Facial Recognition WiFi Terminal (IP65) / Up to 1.5 meters reading / Supports P2P Hik-Connect / 3,000 Users / QR and Video Intercom (low-noise environments)
Deep Learning Speed Demo
Test on Twins with Deep Learning
Speed at Turnstiles with Deep Learning
- 4.3-inch touchscreen
- 2 MP camera with dual lens, wide angle.
- Face detection distance: 0.3 m to 3 m.
- Recognition Distance 0.3 to 1.5 m
- Supports up to 3,000 faces.
- Capacity for 150,000 events.
- Supports up to 3,000 fingerprints.
- Supports up to 3,000 cards (Mifare) ACCESS-CARD-M1K, ACCESSCARDM4K, ACCESKFBM1K.
- Standalone operation or with IVMS4200.
- Warranty: 2 Years.
- - IVMS4200 Scope (data sheet)
- – HikCentral (via license).
- Power supply: 12 VDC / 2 Amp / 24 W. (Included)
- Application: Indoor / Outdoor protected (IP65)
- Temperature: -30°C to 60°C (-22°F to 140°F)
- Dimensions: 172.5 mm × 83.2 mm × 22.7 mm
-
Interfaces:
- Network Port: 1 ( also WiFi )
- Electric Lock: 1
- USB 2.0: 1
- RS-485: 1
- Exit button: 1
- Configurable Wiegand (Input/Output).
The DS-K1T341 series head-mounted terminal adopts a DEEP LEARNING algorithm that helps recognize people's faces faster and more accurately. It's applicable in scenarios such as buildings, enterprises, industries, and other important areas.
- Compatible monitors:
- DS-KH6220-LE1 (local only, no call to the App).
- DS-KH6320-WTE1
- DS-KH8520-WTE1
- DS-KH9510-WTE1
- DS-KH9310-WTE1
Patented DEEP LEARNING algorithm
Reader developed with the world's most advanced facial recognition algorithm, faster than any other and more secure due to its patented, unforgeable algorithm.
- ✓ Works as a Multi-apartment IP Video Intercom (Touch).
- ✓ Proximity card opening for residents.
- ✓ Opening with QR codes from Smartphone.
- ✓ Records as a conventional IP camera on a DVR or NVR
- ✓ Compatible with IVMS4200 Integration software.
- ✓ IP65 for protected outdoor installation (Not weatherproof).
* Mounting for installation on DS-KAB6-ZU1 turnstile
Free SDK for your own integrations available: Download Here.
Video intercom function recommended for quiet environments.
* HikConnect Smartphone App call function is possible through Hikvision IP monitors such as model DS-KH6320-WTE1 if the system is multi-apartment. It can be configured without monitors but to always dial to a single HikConnect account.
HIKVISION Magnetic Plate
Model: DS-K4H258S (Not included in this biometric)
Hikvision launches its own magnetic sheet model, allowing the entire solution to be seen under one brand.
– 600 lbs of force (280 Kg).
✓ CE certified.
✓ LED indicator
Z and L mounts (Required)
The 'Z' and 'L' mounts are required for the installation of the magnetic plates, they are purchased separately and the model is DS-K4H258-L/Z.
IVMS4200 Integration Demo
(Access + Assistance + CCTV + Video Intercoms)
Implementation of integration with APP and other products
Out of stock
MODELO: DS-K1T341CMFW
