PLANET
24-Port Gigabit 10/100/1000T Layer 2 Managed Switch, 2 SFP 100/1000X Ports, Features a Console Interface
24-Port Gigabit 10/100/1000T Layer 2 Managed Switch, 2 SFP 100/1000X Ports, Features a Console Interface
Regular price
$1.049.880 COP
Regular price
$1.148.307 COP
Sale price
$1.049.880 COP
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
24-Port Gigabit 10/100/1000T Layer 2 Managed Switch, 2 SFP 100/1000X Ports, Features a Console Interface
Features
 |
 |
| Hardware specifications | |
|---|---|
| Hardware version | 2 |
| Copper Ports | 24 ports 10/100/1000BASE-T RJ45 auto-MDI/MDI-X |
| SFP/mini-GBIC slots | 2 100/1000BASE-X SFP interfaces, supporting 100/1000 Mbps dual mode |
| Console | 1 RS232 to RJ45 serial port (115200, 8, N, 1) |
| Dimensions | 445 x 207 x 45 mm (1U height) |
| Weight | 2.1 kg |
| Housing | Metal |
| Energy requirements | 100~240 VAC, 50/60 Hz, 0.8 A (max.) |
| Power consumption/dissipation | max. 14 Watts/47 BTU |
| Switch fabric | 52 Gbps/non-blocking |
| MAC Address Table | 8K tickets |
| Flow control |
IEEE 802.3x Pause Frame for Full Duplex Backpressure for Duplex half |
| Marco Jumbo | 9216 bytes |
| Basic management interfaces |
RS232 to RJ45 Console Web browser Telnet SNMP v1, v2c |
| Storage |
Temperature: -10 ~ 70 degrees C Relative humidity: 5 ~ 95% (non-condensing) |
| Operating |
Temperature: 0 ~ 50 degrees C Relative humidity: 5 ~ 95% (non-condensing) |
| Layer 2 Features | Port Mirroring, VLAN, Link Aggregation, Spanning Tree Protocol,IGMP Snooping, MDL Snooping, Access Control List, QoS, Ring |
| Operating temperature |
Temperature: 0 ~ 50 degrees C Relative humidity: 5 ~ 95% (non-condensing) |
| Storage temperature |
Temperature: -10 ~ 70 degrees C Relative humidity: 5 ~ 95% (non-condensing) |
|
Package Included |
- 1 Switch GS-4210-24T2S - 1 Installation Guide - 1 RS232 to RJ45 cable - 4 Rubber bands - 2 Rack mounts - 1 Cable for voltage source - Protector for SFP ports |
Warranty |
3 Years |
- User-friendly management interface, User privilege level control, PLANET NMS and CloudViewer system for deployment management, Cable diagnostics
Out of stock
MODELO: GS-4210-24T2S
