RFS PENETRATOR Omnidirectional Antenna, 806-869 MHz, 10 dBd 500 Watt, N Female

RFS PENETRATOR Omnidirectional Antenna, 806-869 MHz, 10 dBd 500 Watt, N Female

RFS PENETRATOR Omnidirectional Antenna, 806-869 MHz, 10 dB, 500 Watt, N Female.

Electrical Specifications

• Horizontal Pattern: Omnidirectional.
• Frequency Range: 806-869 MHz.
• Horizontal Opening: 360°
• Fixed electric tilt: 0.75 degrees.
• Gain dBi (dBd): 12.1 (10)
• Vertical Opening: 5°
• Polarization: Vertical
• VSWR: < 1.5:1
• Impedance: 50 Ohm
• Input Power (max.): 500 Watt
• Surge Protection: Upper rod grounded to Base assembly.

General Specification

• PENETRATOR

Mechanical Specifications

• Connector Type: N Female
• Connector Placement: Bottom
• Weight: 25 kg
• Weight with B1 Assembly: 39 kg
• Mounting Type: Bracket
• Mounting Hardware: Bracket B1 (Included)
• Maximum wind speed: 225 km/h
• Total Length: 3.96 m
• Diameter: 163.3 mm
• Radiant Element Material: Aluminum
• Radome Material: Fiberglass
• Shipping Weight: 37.7 kg.

*Ask for delivery time.
