TP-LINK
VDM Singlemode Multimedia Converter, 1 RJ45 10/100 port, 1 SC/UPC port, up to 20KM, Requires MC112CS model for operation
VDM Singlemode Multimedia Converter, 1 RJ45 10/100 port, 1 SC/UPC port, up to 20KM, Requires MC112CS model for operation
Regular price
$237.914 COP
Regular price
$260.218 COP
Sale price
$237.914 COP
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
VDM Singlemode Multimedia Converter, 1 RJ45 10/100 port, 1 SC/UPC port, up to 20KM, Requires MC112CS model for operation
For its operation it requires the MC112CS model.
| MEDIA CONVERTER AND MODULE | |
|---|---|
| Standards and Protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Basic Function | Adopts WDM technology Half/Full-Duplex transfer mode for FX port Full Duplex Flow Control (IEEE 802.3x) Half Duplex Flow Control (Backpressure) Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely Extends fiber distance up to 20km |
| Ports | 1 100M SC/UPC port 1 100M RJ45 port (Auto MDI/MDIX) |
| Wave Length | 1550nm Tx/1310nm Rx |
| WDM TX | 1550nm |
| WDM RX | 1310nm |
| Network Media 10BASE-T | UTP category 3, 4, 5 cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
| Network Media 100BASE-T | UTP category 5, 5e cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m) |
| Network Media 100BASE-FX | Single-mode Fiber |
| LED Indicators | PWR, FDX/Col, Link/Act, SPD |
| Dimensions (W*D*H) | 9.5*7.4*2.8cm. (94.5*73.0*27.0mm) |
| Power Supply | External Power Adapter |
| Max Power Consumption | 2.49W |
| Safety & Emission | FCC, CE, RoHS |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Share
Low stock: 7 left
MODELO: MC111CS
