TurboHD OUTDOOR Transceiver Kit (Baluns) Up to 4K HD-TVI / HD-CVI / AHD / CVBS / COAXITRON / AUDIO BY COAXITRON / OSD Menu / 100% COPPER CONNECTORS / With Shielded RF Cable. Distance up to 200 m in 4K. PREMIUM Quality
TurboHD OUTDOOR Transceiver Kit (Baluns) Up to 4K HD-TVI / HD-CVI / AHD / CVBS / COAXITRON / AUDIO BY COAXITRON / OSD Menu / 100% COPPER CONNECTORS / With Shielded RF Cable. Distance up to 200 m in 4K. PREMIUM Quality
Regular price
$22.444 COP
Regular price
$24.548 COP
Sale price
$22.444 COP
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
TurboHD OUTDOOR Transceiver Kit (Baluns) Up to 4K HD-TVI / HD-CVI / AHD / CVBS / COAXITRON / AUDIO BY COAXITRON / OSD Menu / 100% COPPER CONNECTORS / With Shielded RF Cable. Distance up to 200 m in 4K. PREMIUM Quality
TT-101-F-TURBO-EXT
Transceiver Kit
NOTICE: Be sure to use tape on the connectors
BNC Connectors 100% Copper - Competitors use Zinc Alloy Copper connectors offer higher conductivity, better performance at high frequencies (HD Video and long distances) and much lower attenuation
Characteristics
- Real RF Shielded Cable
- Shielded RF cable offers increased noise immunity
- TURBOHD Passive Transceiver Kit
- Real-time transmission over UTP cat 5e/6 cable
- They do not require feeding
- Supported video formats NTSC, PAL, SECAM
- Compatible with analog / TurboHD (TVI) cameras
- Built-in surge protection
- Anti-static wave filter design
- Noise immunity of 60 dB
Physical Specifications
- BNC male connectors
- Pin terminals for UTP cable
- Impedance 75 ohms
- Color: Black
- Operating temperature: -20°C to 70°C
- Dimensions ( L x W x H ): 35.1 x 16.7 x 18.7 mm
- Weight: 40 grams.
Applications
- CCTV monitoring and recording systems.
- 200 meters HD-TVI 5MP transmission.
- 150m HD transmission in 4K
*Price per Kit
Out of stock
MODELO: TT-101-F-TURBO-EXT
