TENMA Compact Benchtop Analog Oscilloscope, 2 Channels, 100 MHz.

TENMA Compact Benchtop Analog Oscilloscope, 2 Channels, 100 MHz.

TENMA Compact Benchtop Analog Oscilloscope, 2 Channels, 100 MHz.

Specs

• Channels: 2.
• Bandwidth: 100MHz.
• Sampling rate: 1Gs/s.
• Rise time: ≤3.5ns.
• Memory depth: 25kpts.
• Waveform acquisition rate: ≥2000wfms/s.
• Vertical sensitivity (V/div): 1mV/div ~ 20V/div.
• Timebase Range (s/div): 2ns/div ~ 50s/div.
• Storage: Configuration, Wave, Bitmap.
• Shooting modes: Edge, Pluse, Alternate.
• Interface: USB OTG.

General characteristics

• Power: 100 - 240V AC, 45 - 440Hz.
• Display: 7 inch TFT LCD, WGVA (800×480).
• Product color: white and gray.
• Net weight of product: 2.2kg.
• Product size (W × H × D): 306mm × 147mm × 122mm.
• Standard Accessories: Probe × 2 (1 ×, 10 × switchable), power cable, USB cable, PC software CD.
• Safety rating: CAT II 300V.
