L2+ Managed Switch 24 ports 10/100/1000 Mbps, 4 SFP Combo Ports

L2+ Managed Switch 24 ports 10/100/1000 Mbps, 4 SFP Combo Ports

Cost-effective IPv6 managed Gigabit switch solution for businesses
PLANET The WGSW-24040 series is a Layer 2+ managed Gigabit switch which features 24 x 10/100/1000BASE-T ports + 4 x shared 100/1000BASE-X SFP ports and supports static Layer 3 routing for enterprise-grade network. The abundant L2/L4 switching engine offered by the WGSW-24040 series realizes effective data traffic control for enterprise and service provider VoIP, video streaming, and multicast applications. Providing easy-to-use yet advanced IPv6/IPv4 management interfaces, it is ideal for backbone and workgroup applications by providing accessibility, high performance, and stable transmission quality.

Physical port

• 24 10/100/1000BASE-T RJ45 copper ports
• 4 x 100/1000BASE-X mini-GBIC/SFP slots, shared with Port-21 to Port-24 supporting 100BASE-FX SFP
• Console interface for basic administration and configuration

Layer 2 Functions

• High-performance Store-and-Forward architecture and runt/CRC filtering eliminate erroneous packets to optimize network bandwidth
• Storm Control Support
• - Broadcast / Multicast / Unknown-unicast

• Supports VLAN
• - IEEE 802.1Q tagged VLAN

• - Up to 255 VLAN groups, 4094 VLAN IDs

• - Supports vendor bridging (VLAN Q-in-Q, IEEE 802.1ad)

• - Private VLAN Edge (PVE)

• - Protocol-based VLAN

• - MAC-based VLAN

• - Voice VLAN

• - GVRP (GARP VLAN Registration Protocol)
• Supports Spanning Tree protocol
• - IEEE 802.1D Spanning Tree Protocol (STP)

• - IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)

• - IEEE 802.1s Multiple Spanning Tree Protocol (MSTP), per-VLAN spanning tree

• - BPDU Guard

• Supports link aggregation
• - 802.3ad Link Aggregation Control Protocol (LACP)

• - Cisco ether-channel (static link)

• - Maximum 10 trunk groups, up to 16 ports per trunk group

• - Bandwidth up to 32 Gbps (full duplex mode)
• Provides port mirroring (many to 1)
• Port mirroring to control incoming or outgoing traffic on a particular port
• Loop protection to prevent broadcast loops
• Supports Cisco Unidirectional Link Detection ( UDLD) that monitors a link between two switches and blocks ports at both ends of the link if the link fails at any point between the two devices.

Quality of service

• Input and Output Speed ​​Limit by Port Bandwidth Control
• 8 priority queues on all switch ports
• Traffic classification
• - IEEE 802.1p CoS

• - TOS/DSCP/IP precedence of IPv4/IPv6 packets

• - TCP/UDP IP port number

• - Typical network application
• Strict priorities and CoS policies for Round Robin pellets (WRR)
• Supports QoS and In/Out bandwidth control on each port
• Traffic control policies on the switch port
• DSCP commenting

Multicast

• Supports IGMP snooping v1, v2 and v3
• Supports MLD snooping v1 and v2
• Querier mode support
• IGMP snooping port filtering
• MLD snooping filtering port
• Multicast VLAN Registration (MVR) Support

Security

• Authentication
• - IEEE 802.1x port-based/MAC-based network access authentication

• - Built-in RADIUS client to cooperate with RADIUS servers

• - TACACS+ login users have access to authentication

• - RADIUS/TACACS+ users have access to authentication
• Access control list
• - IP-based Access Control List (ACL)

• - MAC-based access control list
• Source MAC/IP Address Binding
• DHCP Snooping to filter untrusted DHCP messages
• Dynamic ARP inspection discards ARP packets with an invalid MAC address for the IP address binding.
• IP Source Protection prevents IP spoofing attacks
• Automatic DoS rule to defend against DoS attacks
• IP address access management to prevent unauthorized intruders

administration

• IPv4 and IPv6 dual stack management
• Switch management interfaces
• - Console Command Line Interface / Telnet

• - Web switch management

• - SNMP v1, v2c, and v3 switch management

• - Secure SSH/SSL access

• IPv6 IP address / NTP / DNS management
• Built-in Trivial File Transfer Protocol (TFTP) client
• BOOTP and DHCP for IP address assignment
• System maintenance
• - Firmware upload/download via HTTP/TFTP

• - Reset button to reboot the system or reset to factory defaults

• - Dual images
• DHCP Relay
• DHCP Option82
• DHCP server
• Controlling user privilege levels
• NTP (Network Time Protocol)
• Link Layer Discovery Protocol (LLDP) and LLDP-MED
• Network diagnostics
• - ICMPv6 / ICMPv4 Remote Ping

• - Cable diagnostic technology provides the mechanism to detect and report potential wiring problems
• SMTP/Syslog Remote Alarm
• Four RMON groups (history, statistics, alarms and events)
• SNMP Trap for Link Up Interface and Link Down Notification
• System log
• PLANET Smart Discovery Utility to implement management

Redundant Power Supply System (WGSW-24040R)

• Redundant 100~240V AC / 36-60V DC dual power
• Active-active redundant power failure protection
• Catastrophic power failure backup at one source
• Fault tolerance and resilience
