24 Vdc @ 10 A power supply / With backup battery capability / 1 output / Batteries required / Input voltage: 115 Vac.

24 Vdc @ 10 A power supply / With backup battery capability / 1 output / Batteries required / Input voltage: 115 Vac.

AL1024ULX is a 24 Vdc @ 10 A, 1 output power supply with backup capability, with an input voltage of 115VAC, 60Hz

Entrance

• Input 115VAC, 60Hz, 4.2A.
• Input fuse rated at 3.5 A / 250 V

Exit

• 24VDC output.
• 10 A DC power supply for access control applications.
• 8A DC power supply for fire alarm applications.
• Electronically regulated and filtered output.
• Short circuit and thermal overload protection.

Backup battery

• Built-in charger for sealed lead acid or gel batteries.
• With backup battery capacity.
• Batteries are not included.
• Suggested batteries: PL4.512 / PL712 / PL912.
• Automatic switch to standby battery when AC fails.

Supervision

• AC fault supervision ('C' contacts).
• The notification trigger can be selected for 30 seconds (factory set) or 6 hours.
• Low battery supervision ('C' contacts).
• Battery presence monitoring ('C' contacts).

Visual indicators

• AC input and DC output LED indicators.

Temperature

• Operating from 0 to 49°C (32 to 120°F).
• Storage: 20 to 70°C (4 to 158°F).
• Relative humidity 85% +/- 5%
• BTU/Hr. (approx.): 123 BTU/Hr.

Dimensions

• 12.25'W x 15.5'H x 4.5'D (311mm W x 394mm H x 114mm D).

Weight

• Cabinet: 10.9 Lbs (4.95 Kg)
• Box: 11.90 Lbs ( 5.4 Kg )
