MIKROTIK

(wAP 60G) CPE and PtP in 60GHz, "Up to 1Gbps at 100m"

Name: (wAP 60G) CPE and PtP in 60GHz, "Up to 1Gbps at 100m"
Brand: MIKROTIK
SKU: RBWAPG-60AD
Price: 911063.00 COP
Availability: OutOfStock

$911.063 COP

~~$996.475 COP~~ $911.063 COP

Sale Sold out

Shipping calculated at checkout.

Quantity

(wAP 60G) CPE and PtP in 60GHz, "Up to 1Gbps at 100m"

The wAP 60G is a weatherproof, integrated 60 GHz wireless unit that can be used indoors or outdoors as a point-to-point unit or CPE.

The box includes a wall-mount kit, pole-mount straps, a power supply, a PoE injector, and a tabletop stand for indoor use. Some windows may be penetrated, depending on the material.

wAP 60G connects to a 60 GHz AP for distances over 200 m

Specs

Details
Product code	RBwAPG-60ad
Architecture	ARM32bit
CPU	IPQ-4019
CPU core count	4
Nominal CPU frequency	716 MHz
Dimensions	185 x 85 x 30 mm
RouterOS License	3
Operating system	RouterOS
RAM size	256 MB
Storage size	16 MB
Storage type	FLASH
Room temperature tested	-40°C to 70°C
MTBF	Approximately 100,000 hours at 25°C

Feeding

Details
PoE in	802.3af/at
PoE in input voltage	11-57 V
Number of DC inputs	2 (DC jack, PoE-IN)
DC jack input voltage	11-57 V
Maximum energy consumption	5 W
Fan count	Passive

Ethernet

Details
10/100/1000 Ethernet ports	1

Certifications and approvals

Details
Certification	CE, FCC, IC, EAC, ROHS

Ethernet test results

RBwAPG-60ad		IPQ-4019 1G one port test
Mode	Configuration	1518 bytes		512 bytes		64 bytes
Mode	Configuration	kpps	Mbps	kpps	Mbps	kpps	Mbps
Bridging	none (fast path)	81.2	986.1	234.9	962.2	1482.6	759.1
Bridging	25 bridge filter rules	81.2	986.1	227.7	932.7	231.9	118.7
Routing	none (fast path)	81.2	986.1	235.1	963.0	1421.8	728.0
Routing	25 simple queues	81.2	986.1	235.1	963.0	458.3	234.6
Routing	25 IP filter rules	81.2	986.1	234.9	962.2	236.8	121.2

All tests are done with Xena Networks specialized test equipment (XenaBay), and done according to RFC2544 (Xena2544)
Max throughput is determined with 30+ second attempts with 0.1% packet loss tolerance in 64, 512, 1518 byte packet sizes
Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results
