12 Megapixel (4K) NVR / 128 IP Channels / 16 Hard Drive Bays / 4 Network Ports / Supports RAID with Hot Swap / High Performance NVR

• Compression: H.265+ / H.265 / H.264+ / H.264.
• Support USB mouse to operate the NVR.
• Supports PTZ.
• Supports redundant recording.
• Supports Hot Swap with RAID: 0,1,5,6,10. (Minimum 4TB hard drive capacity for RAID).
• Supports ANR technology with HIKVISION IP camera when the network is disconnected.
• Supports Hot Spare so you never lose recording if your NVR fails (another NVR that also supports the feature is required).
• Supports remote access via phone: Android, iPhone, iPad (app IVMS-4500 / Hik-Connect).
• How much DAS system with 16 internal bays of up to 10 TB each (160 TB total).
• Supports ONVIF (Version 2.5).
• Supports multiple brands such as: HIKVISION, ACTi, ARECONT, AXIS, BOSCH, BRICKCOM, CANON, HUNT, PANASONIC, PELCO, PSIA, RTSP, SAMSUNG, SONY, VIVOTEK, ZAVIO.

• Supports redundant power supplies and cooling fan (included).
• Dimensions: 447 × 528 × 172mm (4U rack).
• Consumption: 140 W without hard drives.
• Power supply: 100 to 240 Vac, 550 W.
• Operating temperature: 0 to 50 °C.
• Weight: 23 Kg without hard drives.
• Warranty: 5 years.

Input/Output Interfaces:

• HDMI 1 and HDMI 2 (independent outputs): 4K / 1080p / 720p.
• Alarm inputs: 16
• Alarm outputs: 8
• Supports RCA audio input and output (two-way audio).

• Input throughput: 576 Mbps (576 Mbps in RAID mode)
• Output throughput: 512 Mbps (512 Mbps in RAID mode)
• Supports 4 10/100/1000 Mbps network cards.
• Supports Fail lover (fault tolerance), Multi address and Load balancing.
• Protocols: IPv6, HTTPS, UPnP, SNMP, NTP, SADP, SMTP, NFS, iSCSI, PPPoE.
• Supports DDNS: DynDNS, No-IP.
• Recording resolution per channel (recommended with H.265):
• 1 Megapixel: 128 channels @ 30 IPS.
• 2 Megapixel: 128 channels @ 30 IPS.
• 5 Megapixel: 128 channels @ 15 IPS.
• 8 Megapixel (4K): 128 channels @ 10IPS.
• Note: The number of recording channels may vary depending on the camera resolution, IPS and bit rate. For more information, please contact the SYSCOM Engineering Department.

• Multi-zone motion detection.
• Digital zoom in viewing and recording.
• Supports multiple recording types, including real-time, manual recording, video sensor, external alarm, video sensor and alarm, video sensor or alarm.
• Playback of recordings up to 16 simultaneous channels.
• Supports recording up to 12 MP per channel.
