TP-LINK's TL-WA801ND Wireless N Access Point is designed to establish or expand a scalable, high-speed Wireless N network or to connect multiple Ethernet devices such as game consoles, media players, printers, or network storage devices to a wireless network. It supports a wide variety of features and configurations, giving you more flexibility for your network. Now you can enjoy a better internet experience when downloading content, gaming, streaming video, or anything else.

• 300Mbps wireless transmission speed, provides a smooth wireless N experience
• It supports multiple operation modes: Access Point, Client, Universal/WDS Repeater, Wireless Bridge
• Easy setup of a secure WPA encrypted connection by pressing the QSS button
• Flexible installation: up to 30 meters (100 feet) away using the supplied Power over Ethernet injector

Characteristics

• One 10/100 Mbps Ethernet port (RJ45)
• Support for passive PoE
• External Power Supply 9VDC / 0.85A
• Frequency 2.4-2.4835GHz
• Transmitting Power <20dBm(EIRP)
• Wireless Modes Access Point/Multiple SSIDs/Access Point Client/Repeater/
• Universal repeater/bridge+access point
• Advanced Features PoE support up to 30 meters

Physical and electrical characteristics

• Dimensions 181*125*36 mm (7.1*4.9*1.4 inches)
• Antenna Type 2 x 5 dBi, detachable omnidirectional (RP-SMA)
• Operating temperature: 0℃~40℃ (32℃~104℃)
• Storage temperature: -40℃ ~ 70℃ (-40℉ ~ 158℉)
• Operating humidity: 10% ~ 90% non-condensing
• Storage humidity: 5% ~ 90% non-condensing

Includes

• Wireless Access Point TL-WA801ND
• Power supply
• PoE power injector
• Resource CD
• Quick Installation Guide
