Access Controller for 2 Readers / 30,000 Cards / 20,000 Events / Includes Cabinet and Power Supply / New Generation!

This AC-215IP-B access controller distinguishes the type of multiple credentials for connected terminals.

You can register and use various types of credentials for multi-factor authentication, event logging, and automation.

CHARACTERISTICS

Controller

• 30,000 cards.
• 20,000 records (loop memory).
• 2 inputs for reader (Wiegand) 26 bits.
• Configurable for 1 or 2 doors.
• 2 relays for door opening.
• 2 door status sensor inputs.
• 2 auxiliary relays (programmable).
• Built-in alarm horn.
• Removable screw terminals.
• Cabinet with power supply (input 110 Vac, 1.5, output 12 Vdc, 4 A) with battery charger (not included).
• Dimensions: 326 x 263 x 97 mm.
• Weight 2.4 kg.

Communication

• RS485 (G-BUS).
• TCP/IP.

Compatible software AXTRAXNG version 27.5.7.8

• AXTRAX NG Software (Level 0) in Spanish/English.
• Suggested Windows 7 Professional for AXTRAXNG versions prior to version 26, recommended for AXTRAXNG 26.5.4.8 Windows 8 Pro.
• Database in SQL Server.
• It works as a client/server.
• Ability to manage up to 1,023 doors (With licenses*).
• Operator level programming.
• Supports up to 64 controllers (free).
• 32 schedules.
• 128 authorization groups.
• Real-time monitoring.
• Ability to incorporate photographs.
• Antipassback and global antipassback function.
• User-friendly reports by user and department.
• Support for manual and automatic programming.
• Virtual map capacity.
