IP Camera / 3 Megapixels / Outdoor IP66

IP Camera / 3 Megapixels / Outdoor IP66

General characteristics:

The NL-Ghost OV camera utilizes an ultra-sensitive, high-resolution CMOS sensor and a quad-core internal processor to deliver superior performance in traffic analytics applications up to two lanes. A single unit integrates the camera, LED strobe lighting, electronic lighting control, and Neural Labs traffic analytics such as license plate reading, speed estimation, color and vehicle make detection, and more.

Specs:

• 2-way reading, using sensor options 3.2
• Read multiple license plates in a single field of view.
• Top low light sensor: 1/1.8' CMOS Global Shutter.
• 25mm fixed lens / 35mm lens for working from 15 to 25 meters away.
• Capture plate and context from the same unit.
• 23 LEDs to illuminate up to 2 traffic lanes.
• High temperature range CPU.
• VPAR SERVER included (Free Flow ANPR, LPR)
• Color surround camera included.
• Video analytics available (Instant speed, Classification, Direction of travel and Lane. Coming soon: Vehicle make and color)
• Average Speed ​​Calculation, Photo Red Control, Photo Stop Control, Wrong Turn Control, Wrong Way Detection

Physical and electrical characteristics:

• Power supply: 24VDC.
• Consumption: 150W - 24 V.
• Standard storage: 40GB expandable up to 640GB.
• Standard Mounting: IP66.
• LED Quantity: 23 LEDS.
• Maximum infrared light range: Optimized 10 - 30 meters.
• Infrared beam angle: 20 °/ 40 °.
• Power supply: 24VDC.
• Protection rating: IP66.
• Dimensions: 365mm x 234mm x 154mm (L, W, H).
• Net Weight: 3.5 Kgs.
• Housing material: Aluminum.
