MIKROTIK
(mANTBox 2 12s) 2.4 GHz PTP and PTMP Access Point with Integrated 12 dBi Sector Antenna and 120° Opening, Up to 1000 mW Power
(mANTBox 2 12s) 2.4 GHz PTP and PTMP Access Point with Integrated 12 dBi Sector Antenna and 120° Opening, Up to 1000 mW Power
Regular price
$559.119 COP
Regular price
$611.537 COP
Sale price
$559.119 COP
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
(mANTBox 2 12s) 2.4 GHz PTP and PTMP Access Point with Integrated 12 dBi Sector Antenna and 120° Opening, Up to 1000 mW Power
mANTBox 2 12s is a long range, 12dbi, 120 degree integrated base station for 2.4GHz.
The MANTBox is based on our new mANT sector antennas, but also has an integrated wireless router. Powered by the RB911 device, the mANTBox comes ready to use with everything included. The device uses a high-speed 600 MHz CPU, comes with a Gigabit Ethernet port, and has an integrated 802.11 b/g/n wireless router with an output power of up to 30 dBm.
Specs
| Details | |
|---|---|
| Product code | RB911G-2HPnD-12S |
| Architecture | MIPSBE |
| CPU | AR9342 |
| CPU core count | 1 |
| Nominal CPU frequency | 600 MHz |
| Dimensions | 140 x 348 x 82 mm |
| RouterOS License | 4 |
| Operating system | RouterOS |
| RAM size | 64 MB |
| Storage size | 128 MB |
| Storage type | NAND |
| Room temperature tested | -40°C to 70°C |
| MTBF | Approximately 100,000 hours at 25°C |
Feeding
| Details | |
|---|---|
| PoE in | Passive PoE |
| PoE in input voltage | 10-28 V |
| Number of DC inputs | 2 (DC jack, PoE-IN) |
| DC jack input voltage | 8-30 V |
| Maximum energy consumption | 11 W |
| Fan count | Passive |
Wireless specifications
| Details | |
|---|---|
| Maximum wireless data rate of 2.4 GHz | 300 Mbit/s |
| Number of 2.4 GHz wireless chains | 2 |
| 2.4 GHz wireless standards | 802.11b/g/n |
| Antenna gain dBi for 2.4 GHz | 12 |
| 2.4GHz Wireless Chip Model | AR9342 |
| 2.4 GHz wireless generation | Wi-Fi 4 |
Ethernet
| Details | |
|---|---|
| 10/100/1000 Ethernet ports | 1 |
Other
| Details | |
|---|---|
| PCB Temperature Monitor | Yeah |
| Voltage monitor | Yeah |
Certifications and approvals
| Details | |
|---|---|
| Certification | CE, FCC, IC, EAC, ROHS |
Wireless specifications
| 2.4 GHz | Transmit (dBm) | Receive sensitivity |
|---|---|---|
| 1 MBit/s | 30 | -100 |
| 11 MBit/s | 30 | -94 |
| 6 MBit/s |
299 in stock
MODELO: RB911G-2HPND-12S
