380-470 MHz Preselector, Compact, 2-5 MHz Wide-Band, 1.5 dB, 450 Watt, N Females.

380-470 MHz Preselector, Compact, 2-5 MHz Wide-Band, 1.5 dB, 450 Watt, N Females.

Compact 380-470 MHz, 450 Watt, N Female Preselector.

• Frequency Range: 380-470 MHz.
• Type: Resonant cavity compact .
• Bandwidth: 2-5 MHz.
• Insertion loss: 1.5 dB.
• Isolation (Typical): 45 dB @ 1.5 MHz from Passband ends.
• Return loss (min): 14 dB.
• Handling Power: 450 Watt.
• Connectors: N female.
• Temperature Range: -30° C to +60° C.
• Dimensions (Width x Height x Depth): 222.3 x 120.6 (3 UR) x 393.7 mm.
• Net Weight: Single = 8.2 kg / Double = 15.9 kg.

*Ask for delivery time.
