CPE de Exterior de 5 GHz a 300Mbps, Antena direccional de 13dBi, potencia de 27 dBm

5GHz 300Mbps Outdoor CPE, 13dBi Directional Antenna, 27dBm Power

Sale price  $365,413 Regular price  $388,712
Skip to product information
CPE de Exterior de 5 GHz a 300Mbps, Antena direccional de 13dBi, potencia de 27 dBm

5GHz 300Mbps Outdoor CPE, 13dBi Directional Antenna, 27dBm Power

Sale price  $365,413 Regular price  $388,712
Shipping calculated at checkout.
Marca
TP-LINK
Referencia / SKU
CPE510
Disponibilidad
6 unidades disponibles
Descripción y especificaciones

5GHz 300Mbps Outdoor CPE, 13dBi Directional Antenna, 27dBm Power

Outdoor CPE 5GHz 300Mbps 13dBi

  • Incorporates a 13dBi 2x2 dual-polarized directional MIMO antenna
  • Adjustable transmit power from 0 to 23dBm / 200mw
  • System-level optimizations for long-range wireless transmission over 15 kilometers
  • TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance, capacity and latency performance, ideal for PTMP applications.
  • Centralized Management System - Pharos Control
  • Operating modes, AP/Client/Repeater/AP Router/AP Client Router (WISP)
  • Passive PoE adapter supports up to 60 meters (200 feet). Power over Ethernet implementation and allows the device to be reset remotely.

HARDWARE FEATURES
Processor Qualcomm Atheros Enterprise 560MHz CPU, MIPS 74Kc
Memory 64MB DDR2 RAM, 8MB Flash
Interface 1 Shielded Ethernet Port 10/100Mbps (LAN0, in Passive PoE)
1 Ground terminal
1 Reset Button
Power Supply Passive Power over Ethernet via LAN0 (+4.5pins; -7.8pins)
Voltage Range: 16-27VDC
Energy Consumption 10.5 Watts Max
Note: When implemented using passive PoE, the power drawn from the power supply will be higher by a certain amount depending on the length of the connecting cable.
Dimensions (WxDxH) 224 x 79 x 60 mm
Antenna Type 2 Built-in 13dBi Dual Polarized Directional Antennas

Beam Width: 45° (H-Plane) / 30° (E-Plane)

Note: For more details, read the data sheet.
Protection 15KV ESD Protection
Lightning Protection 6000V
Fenced Outdoor stabilized ASA plastic material
IPX5 Waterproof Certification
WIRELESS FEATURES
Wireless Standards IEEE 802.11a/n (with Pharos MAXtream disabled)
Owner Protocol TDMA mode (with Pharos MAXtream enabled)
Wireless Speeds Up to 300Mbps (40MHz, Dynamic)
Up to 144.4Mbps (20MHz, Dynamic)
Up to 72.2Mbps (10MHz, Dynamic)
Up to 36.1Mbps (5MHz, Dynamic)
Frequency 5.15~5.85GHz
Note: Available operating frequency may vary depending on the limitations of the countries or regions where the device is used.
Reception Sensitivity • 802.11a:
54M: -75dBm, 48M: -76dBm, 36M: -83dBm, 6-24M: -95dBm
• 802.11n:
MCS15: -73dBm, MCS14: -74dBm, MCS13: -76dBm,
MCS12: -80dBm, MCS11: -83dBm, MCS10: -88dBm,
MCS9: -90dBm, MCS8: -93dBm, MCS7: -73dBm,
MCS6: -74dBm, MCS5: -76dBm, MCS4: -80dBm,
MCS3: -83dBm, MCS2: -88dBm, MCS1: -90dBm, MCS0: -93dBm
Transmission Power 23dBm / 200mw (power adjustable by 1dBm)

Note: Maximum transmission power may vary across different channels depending on the limitations of the countries or regions where the device is used.
SOFTWARE FEATURES
Wireless Settings Pharos MAXtream TDMA Technology
802.11a/n modes
Selectable Channel Width: 5/10/20/40MHz
Automatic Channel Selection
Power Control Transmission
Dynamic Frequency Selection (DFS)
WDS Enable/Disable
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) encryption, 64/128/152-bit WEP encryption
SSID Broadcast Enabled / Disabled
Multi-SSID with VLAN Tagging (AP mode only)
Distance/ACK Timeout Setting
Wireless MAC Address Filter
Advanced Wireless:
> Beacon Interval/RTS Threshold/Fragmentation
>Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
Administration Remote Administration and Discovery via the Pharos Control app
HTTP/HTTPS-based administration
System Log
SNMP Agent (v2c)
Ping Watch Dog
Dynamic DDNS
SSH Server
System tools Wireless Signal Quality Indicators:
Signal Strength/Noise/CCQ Transmission/CPU/Memory Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
Spectrum Analyzer
Speed ​​Test
Ping
Traceroute
System Level Optimizations IGMP Optimized/Proxy for Multicast Applications
Hardware watch dog
POE ADAPTER FEATURES
Dimensions (W x D x H) 110*57*33.5mm
Interfaces 1 AC Jack with Earth Ground
1 Shielded Ethernet Port 10/100Mbps (Power + Data)
1 Shielded Ethernet Port 10/100Mbps (Data)
Button Remote Reset Button
Power Status LEDs 0~0.8A: Green
0.8A~1.0A: Red
Input 100-240VAC, 50/60Hz
Input Voltage 100VA~240VAC @ 50Hz~60Hz
Input Current 0.8A Max @ 100VAC
Output 24VDC, 1.0A Max
+4, 5 pins; -7, 8 pins. (Supports up to 60m Power over Ethernet)
Output Voltage 24VDC(+4.5pins; -7.8pins)
Efficiency >80%
Certifications CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
OTHERS
Certification CE, FCC, RoHS, IPX5
Package Contents Wireless Outdoor CPE
Passive PoE Adapter 24V 0.6A
Pole Mount Straps
AC power cable
Installation Guide
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Note: We recommend using one of the following web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.
Atmosphere Operating Temperature: -30°C~70°C (-22°C~158°C)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
