5-Port Gigabit PoE Switch, with 4 802.3af/at PoE ports up to 56W

5-Port Gigabit PoE Switch, with 4 802.3af/at PoE ports up to 56W

The TL-SG1005P is a 5-port, zero-configuration, 10/100/1000Mbps unmanaged switch with 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power to all IEEE 802.3af-compliant powered devices (PDs). In this situation, power is transmitted along with data on a single cable, allowing you to expand your network to where there are no power lines or outlets, such as where you want to service devices such as APs, IP cameras, or IP phones.

Ports

• 5 10/100/1000 Mbps Ports

PoE Features

• 802.3af Standards
• PoE Ports: 4 Ports
• 56 W

Characteristics

• 5 10/100/1000Mbps RJ45 ports
• With four PoE ports, transfer data and power with a single cable
• By working with IEEE 802.3af compliant PDs, the home and office network is expanded
• Supports PoE Power up to 15.4W per PoE port
• Supports PoE Power up to 58W for all PoE ports
• No configuration or installation required

Includes

• TL-SG1005P
• Power adapter
• User Guide

Physical and Electrical Characteristics

• Operating temperature: 0 ℃ ~ 40 ℉ (32 ℉ ~ 104 ℉)
• Storage temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
• Operating humidity: 10% ~ 90% RH non-condensing
• Storage humidity: 5% ~ 90% RH non-condensing
• Power Consumption: 1.70 watts (maximum without PD connected) 63.51 watts (maximum with 56w PD connected)
• Dimensions 3.9 x 3.9 x 1.0 in. (99.8 x 98 x 25 mm)

5 Gigabit ports with 4 PoE ports, 56W total PoE power
