1 Kilometer of Aerial Optical Fiber (ADSS) G.652D Armed Anti-rodent, Dielectric, Single-mode 6 Wires, Span 200

1 Kilometer of Aerial Optical Fiber (ADSS) G.652D Armed Anti-rodent, Dielectric, Single-mode 6 Wires, Span 200

ADSS (All Dielectric Self-Supported) fiber optic cable is designed for aerial installations between poles. ADSS cables withstand the necessary tensile strength thanks to their aramid strands; they contain no metallic elements.

It also features dielectric armor to protect it from rodents, making it the perfect cable for installations on towers or electric poles.

Technical Specifications:

• Armed Fiber Optic ADSS G.652D Singlemode Anti rodent Loose Tube
• For aerial, pipeline or direct burial installations
• Outer Cover: HDPE (High Density Polyethylene)
• Maximum tension: 7000N
• Anti-tracking (up to 110kV)
• Operating temperature: -20ºC to +65ºC
• Span (Distance between Poles): 200 meters
• UV and moisture protection
• Nominal diameter (D): 13.9 mm ± 0.5 mm
• Minimum bending radius: Installation 25D, Operation 12.5D
• Crush resistance: 1000N/10cm
• Rated weight (kg/km): 160 ± 15 kg/km
• 6 threads
• Price per 1 kilometer

For overhead, pipeline, or direct burial installations. Maximum voltage: 7000N, Span (Distance between Poles): 200 meters, Anti-tracking (up to 110kV).
