(COMPATIBLE with OPTEX Fibersensys) Kilometer of Aerial Optical Fiber (ADSS) G.652D Armoured Anti-rodent, Dielectric, Singlemode 36 Strands, Span 200
ADSS (All Dielectric Self-Supported) fiber optic cable is designed for aerial installations between poles. ADSS cables withstand the necessary tensile strength thanks to their aramid strands; they contain no metallic elements.
It also features dielectric armor to protect it from rodents, making it the perfect cable for installations on towers or electric poles.
Technical Specifications:
- Armed Fiber Optic ADSS G.652D Singlemode Anti rodent Loose Tube
- Outer Cover: HDPE (High Density Polyethylene)
- Maximum tension: 7000N
- Anti-tracking (up to 110kV)
- Operating temperature: -20ºC to +65ºC
- Span (Distance between Poles): 200 meters
- UV and moisture protection
- Nominal diameter (D): 13.9 mm ± 0.5 mm
- Minimum bending radius: Installation 25D, Operation 12.5 D
- Crush resistance: 1000N/10cm
- Rated weight (kg/km): 160 ± 15 kg/km
- 36 threads
- For overhead, pipeline, or direct burial installations. Maximum voltage: 7000N, Span (Distance between Poles): 200 meters, Anti-tracking (up to 110kV).
