PoE Switch / 100 Meters PoE / 8 ports 802.3af/at (132.5 W) 10/100/1000Mbps + 2 Uplink ports

EPCOM POWER LINE switches are designed for video surveillance and structured cabling systems. Featuring 4 and 8 1000Mbps Ethernet ports and two 1000Mbps uplink ports, they support VLAN functionality, effectively preventing broadcast storms throughout the entire system, making data transfer more secure.

Applications:

• Security monitoring system
• Multimedia network teaching system
• Medical monitoring display system
• Industrial automation control system
• Banking, securities and financial information system
• Remote monitoring of the network server
• Department store security
• Casino Security
• Hospitals, Airports and Banks
• School campuses

Physical Ports :

• • 8 10/100/1000 Mbps ports + 2 Up-link ports
  • Support End-Span method
  • Dimensions:
  • Weight: 612 g.

4/8-Gigabit Ports
PoE Switch

ET-1004GP-2G/ ET-1008GP-2G

---

Advantages

More Voltage

Allows you to power PoE devices from 48 to 56 Vdc.

More Power

A highly distributed 120W or 265W AC power for 4 and 8 port switches.

More Wattage

AF/AT supplies 30 W at each point.

More Bandwidth

Get 1 Gb of bandwidth, SFP fiber optic UpLink ports.

More Security

Each surge protector is 6 KV.

Power Supply Mode

Power adapter or internal power supply, corresponding to the model.

---

Characteristics

• • Automatic standard PD identification, intelligent power supply.

• • It does not emit spark when connected and working.

• • The reset function helps the main IC for a full restoration.

• Energy-efficient Ethernet function.

• • Frame loss rate: 0%.

• • Unique ESD protection design.

• Operating temperature from 0° C to 55° C (32° F to 131° F).

---

Application Diagram
