Corner Reflector Directional Antenna, 148-174 MHz, 50 Ohm, 10 dBd (12 dBi), 250 Watt, N Male.

Corner Reflector Directional Antenna, 148-174 MHz, 50 Ohm, 10 dBd (12 dBi), 250 Watt, N Male.

Corner Reflector Directional Antenna, 148-174 MHz, 10 dB.

• Frequency band: 148-174 MHz
• Gain: 10 dBd (12.1 dBi).
• Input VSWR (max): 1.5:1
• Polarization: Vertical / Horizontal.
• Impedance: 50 Ohm.
• Pattern: directional.
• Horizontal beamwidth (typical): 50°
• Vertical beamwidth (typical): 66°
• Average input power: 250 Watt.
• Lightning protection: DC Ground.
• Connector: N Male.
• Front to rear ratio (typical): 30 dB.
• Nominal wind speed (without ice): 314 km/h.
• Temperature range: -40° to +60°C
• Mounting hardware: Clamp004 (included)
• Dimensions (Width x Depth x Length): 2946 x 1575 x 1829 mm.
• Weight: 42.22 kg.
• Shipping dimensions: 2438 x 152 x 610 mm.
