SAE Class 1 LED Mini Rotating Bar, Amber Dome, Permanent Mount

SAE Class 1 LED Mini Rotating Bar, Amber Dome, Permanent Mount

The 5280 Series RotoLED™ minibar combines all the benefits of the latest LEDs with the unmistakable warning signal of a rotor, all without compromising reliability.

Hybrid LED technology uses a brushless magnetic drive system to rotate the reflector disc, reducing noise and eliminating the typical motor/gear drawbacks associated with conventional rotors.

Each hybrid module also features 8 high-intensity LEDs and TIR optics, providing SAE Class I light output. Additional benefits include low amp draw, long service-free life, and a 5-year warranty.

Features and benefits:

12-24 VDC, 3.7 Amps, 360 FPM

Measurements: 13.3' x 6.3' x 5.8' (33.7 X16 X 14.6 cm)

• No gears, brushes or bulbs to remove

• LED optics produce an intense rotating beam

• UV hard coated lens reduces abrasion, cracking and discoloration.

• Temperature range: -22°F to +122°F (-30°C to +50°C)

45° angled reflector driven by a silent brushless magneto, gears, or belts, the system provides an exceptional warning beam without compromising reliability

High intensity 3 Watt LEDs, combined with unique TIR optics, project light onto the reflector to provide SAE Class I light output.

5 Year Warranty, SAE CLASS I, CA TITLE 13, CE, R10, R65, IP67, ROHS Compliant, No gears, brushes, or bulbs to change, Polycarbonate lens and waterproof housing, 12-24 VDC, 3.7 Amp
