• Switch Industrial Administrable Capa 2 con 4 Puertos 10/100/1000T y 2 puertos SFP 100/1000X
1 4

PLANET

Layer 2 Managed Industrial Switch with 4 10/100/1000T Ports and 2 100/1000X SFP Ports

Layer 2 Managed Industrial Switch with 4 10/100/1000T Ports and 2 100/1000X SFP Ports

$1.866.454 COP
$2.041.434 COP $1.866.454 COP
Sale Sold out
Shipping calculated at checkout.

Layer 2 Managed Industrial Switch with 4 10/100/1000T Ports and 2 100/1000X SFP Ports

Applications



Hardware specifications
Copper ports 4 10/100/1000BASE-T RJ45 auto-MDI/MDI-X ports
SFP / mini-GBIC slots 2 SFP 1000BASE-SX/LX/BX interfaces (port 5 to port 6)
Compatible with 100BASE-FX SFP
Console 1 RJ45 to RS232 serial port (115200, 8, N, 1)
Housing IP30
Facility DIN Rail Kit, Wall Mount Kit
Alarm One power failure relay output. Alarm relay current carrying capacity: 1A at 24V DC
Dimensions (W x D x H) 32 x 87 x 135 mm
Weight 456 g
Power Requirements (Does not include voltage supply) Double 12 ~ 48
VDC 24 VAC
Consumption Max. 6.3 Watts / 21.6 BTU (off-line on)
Max. 8.5 Watts / 29.2 BTU (full load)
Layer 3 function IP Interfaces, Routing Table, Routing Protocols.
Temperature - 40 to 75°C
Package contents

1 x Industrial Switch

1 x Installation Guide

1 x RS232 to RJ45 Console Cable

1 x DIN Rail Kit

1 x Wall mounting kit

2 x SFP port covers

5 x RJ45 port covers

    IP30 housing, Designed for wall or DIN rail mounting, Redundant 12 - 48 Vdc power supply, Protection against reverse polarity, Withstands temperatures from -40 to 75°C

Out of stock

MODELO: IGS-5225-4T2S
