Patch Cord Cat6A, Blindado S/FTP, CM/LS0H, 1m, Color Azul

Patch Cord Cat6A, Shielded S/FTP, CM/LS0H, 1m, Blue

Sale price  $60,732 Regular price  $63,214
Skip to product information
Patch Cord Cat6A, Blindado S/FTP, CM/LS0H, 1m, Color Azul

Patch Cord Cat6A, Shielded S/FTP, CM/LS0H, 1m, Blue

Sale price  $60,732 Regular price  $63,214
Shipping calculated at checkout.
Marca
PANDUIT
Referencia / SKU
STP6X1MBU
Disponibilidad
Agotado por ahora
Descripción y especificaciones

Patch Cord Cat6A, Shielded S/FTP, CM/LS0H, 1m, Blue

The TX6A™ Cat 6A shielded patch cable is constructed of 26 AWG shielded twisted-pair CM/LSZH cable with enhanced-performance modular plugs. The patented tangle-free latch prevents snagging and provides easy release, saving time during frequent moves, adds, and changes. The slim strain-relief boot on the patch cord provides easy access in high-density applications. The cable is 1 meter long and blue in color.

Specs

Application (1) Switch-to-switch stacking links (2) Gigabit Ethernet channel aggregation (3) Video streaming (4) Scientific modeling (5) Storage area networks (6) Real-time intensive financial transactions (7) Animation (8) Medical imaging
Product type Armored Patch Cord
Wire gauge (AWG) 26
Conductor gauge (kcmil) 0.3
Sub Brand Pan-Net®
Performance level Category 6A
Driver Type Braided
Cable Construction S/FTP
Patch Cord Type Armored
Connector housing material Polycarbonate
Connector Type 1 Modular
Connector Type 2 Modular
Total length (m) 1
Nominal outer diameter of the cable (mm) 6.1
Wiring diagram T568B
Maximum operating temperature (°C) 60
Minimum operating temperature (°C) -10
Maximum Storage Temperature (°C) 70
Maximum Storage Temperature (°C) -40
Cap color Black
Color Blue
Flammability classification Double classification (CM/LSZH)
Standards Exceeds all ANSI/TIA-568.2-D Category 6A and ISO 11801 Class EA standards for all frequencies up to 500 MHz; Meets ANSI/TIA-1096-A; Meets IEC 60603-7; Meets IEC 60332-1, IEC 60754-1, IEC 61034-2; UL 1863; Rated for 2500 cycles with IEEE 802.3af / 802.3at and 802.3bt type 3 and type 4; RoHS Compliant
IEC Variant 60603-7
PoE compatibility PoE/PoE+/PoE++
Connector type 8 Positions
