Symmetrical Sector Antenna, dual 30° sector and 19 dBi, Connectivity for high user density, 4.9-6.5 GHz, Stability in high noise environments, N-Female connector, with mounting included

Technical Specifications

• Frequency: 4.9-6.5 GHz
• Gain: 19 dBi
• MIMO 4x4
• Double double slant (V/H ±45°)
• VSWR < 2.0
• Front to Back Ratio (F/B) 40 dB
• Horizontal beamwidth: 30°
• Vertical beamwidth: 30°
• Maximum power per port: 50 W
• Impedance: 50 Ω.

Mechanical Specifications

• 4 N-Female connectors.
• 2 * 20.8 to 27.8 cm
• Antenna weight 3 kg
• Antenna color: White
• Antenna material: aluminum.
• Tube or fitting diameter .3 cm to 8 cm.
• Mechanical Tilt ± 30°
• Operating Temperature: -40° to +70°C (-32° to +158°F)
• Does NOT include jumpers

NOISE REJECTION

Fast and scalable connection, layers to avoid internal noise between antennas, thus achieving a greater number of wireless links in a single point

Compatibility with any radio on the market

Double connectorization with different radius

Dual polarity (V/H ±45°), Non-existent side lobes, 30° beamwidth, Super lightweight, High gain at 19 dBi, Connectivity for high-density user networks
