Switch Administrable Stackable Capa 2+, 24 Puertos 10G SFP+, 2 Puertos 40G QSFP+, Capacidad de Conmutación Hasta 640 Gbps

Layer 2+ Stackable Managed Switch, 24 10G SFP+ Ports, 2 40G QSFP+ Ports, Switching Capacity Up to 640 Gbps

Sale price  $8,644,555 Regular price  $10,666,497
Skip to product information
Switch Administrable Stackable Capa 2+, 24 Puertos 10G SFP+, 2 Puertos 40G QSFP+, Capacidad de Conmutación Hasta 640 Gbps

Layer 2+ Stackable Managed Switch, 24 10G SFP+ Ports, 2 40G QSFP+ Ports, Switching Capacity Up to 640 Gbps

Sale price  $8,644,555 Regular price  $10,666,497
Shipping calculated at checkout.
Marca
PLANET
Referencia / SKU
XGS-5240-24X2QR
Disponibilidad
Agotado por ahora
Descripción y especificaciones

Layer 2+ Stackable Managed Switch, 24 10G SFP+ Ports, 2 40G QSFP+ Ports, Switching Capacity Up to 640 Gbps

Total switching capacity of 640 Gbps

Centralized IP stack management


High-reliability hardware stacking

Redundant AC and DC power to ensure continuous operation

Hardware specifications
SFP+ slots 24 10GBASE-SR/LR SFP+ interfaces
Compatible with 1000BASE-SX/LX/BX SFP transceiver
QSFP+ slots 2 each supporting native 40 Gigabit Ethernet and four 10GBASE-SR/LR Ethernet modes
MGMT One RJ45 10/100/1000BASE-T port
Console 1 RJ45 to DB9 serial port (9600, 8, N, 1)
USB 1 USB 2.0
Switching capacity 640 Gbps / non-blocking
Dimensions 440 x 318 x 44.6 mm
Weight 4.3 kg
Energy consumption 75 Watts / 210 BTU (maximum)
Energy requirements AC 100~240V, 50/60Hz
DC 36-72 V
Layer 2 functions
Layer 3 functions Routing Protocol, Routing table, DHCP
System Configuration Console, Telnet, Web Browser, SNMP v1, v2c
Secure management interfaces SSH, SSL, SNMPv3
Operating temperature Temperature: 0 ~ 50 degrees C
Relative humidity: 10 ~ 85% (non-condensing)
Storage temperature Temperature: -40~80 degrees C
Relative humidity: 5 ~ 95% (non-condensing)

    Centralized IP stack management (up to 24 switches), High-reliability hardware stacking (up to 4 switches), Fault tolerance and resiliency, Redundant 36-72 VDC power input
