cnPilot XV2-2 WiFi 6 802.11ax Access Point, Dual Band, WPA3 Access Security, Application Control Policies, Up to 512 Clients, Cloud Management

XV2-2 Wi-Fi 6 Access Point

802.11ax
Standard + MESH 512
Omi users
360º cnMaestro or XMS Controller

XV2-2 continues the convergence of the Enterprise network with an intelligent edge Access Point managed by the best Wi-Fi system on the market with applications that will help control our network and keep us informed of everything.

Free management in cnMaestro Comprehensive management of the entire network for inventory management, device onboarding, daily operations, maintenance, configuration, and provisioning, as well as ticket and/or voucher creation, time and bandwidth control, and a captive portal.	Designed for high capacity Triple Play Supports up to 512 active users with high traffic and up to 16 SSIDs.
Aesthetic design for ceiling Designed to be installed on the ceiling of hallways or offices without sacrificing the aesthetics that a network device might create, it adapts to any setting.	Roaming and MESH Backhauling capability for MESH designs and supports Roaming to avoid losing connectivity when moving around rooms.
Guaranteed, categorized as the best Cost-benefit Access Point The XV2-2 offers a reliable, high-capacity indoor Wi-Fi networking solution at a significantly lower cost than its high-end competitors. You'll save network nodes, and we guarantee the equipment for 5 years.	Monitor what's happening on your network. Limit access to restricted pages using the cn Maestro ACL

Wi-Fi 6 designed for mobile and IoT devices.

The XV2-2 is a dual-radio Wi-Fi 6 Access Point designed to deliver next-generation networking with edge services at a very competitive price point. Wi-Fi 6 technology delivers higher network speeds and enables more connected devices with higher packet quality. Wi-Fi 6 brings a deterministic model to the radio frequency (RF) layer, where the AP controls client connections, including when they sleep, when they wake up, and how they transmit and receive packets. The XV2-2 is fully backward compatible with existing Wi-Fi technology and enables massive growth in low-power, low-speed IoT devices to add infrastructure intelligence to any market.

Comparison with other brands

Maximum number of connected devices: 512 Wi-Fi devices.

Operating modes: Access Point or Router (NAT, DHCP Server and Firewall).

Main features:

802.11 a/b/g/n/ac Wave 2/ax standard.

Dual band (2.4 and 5 GHz).

MU-MIMO 2X2.

Up to 573 Mbps at 2.4 GHz.

Up to 1,201 Mbps at 5 GHz.

Omnidirectional Antennas: 5 dBi at 2.4 GHz and 6 dBi at 5 GHz.

Power: 24 dBm at 2.4 GHz and 25 dBm at 5 GHz.

General characteristics:

Management type: Standalone, cnMaestro Cloud Managed (free), and cnMaestro on-premises VM or XMS Cloud.

Up to 16 SSIDs (Flexible on any band)

Fast Roaming: Browse from cell to cell without losing connection.

ACL: Create blocking rules for web pages.

ACS function for automatic channel switching to avoid interference.

Schedule SSID to activate SSID on desired days at certain times.

Captive portal Hotspot from the cloud, customizable vouchers.

Limit bandwidth per user or SSID.

Isolation between clients to prevent broadcast and multicast storms from entering the network.

Load Balancing to balance the load between each band.

Supports MESH.

Physical and electrical characteristics.

1 port 2.5 Gbps PoE IN 802.3at, powered by cnMatrix Switches or PoE power supply model N000000L042A, not included).

Maximum consumption: 21 W

Free management via cnMaestro controller from the cloud, no additional hardware required.

Package includes the following:

Requires PoE power supply model N000000L034A.
