1/2" Low Loss Coaxial Cable Meter, LMR600 50 Ohms

1/2" Low Loss Coaxial Cable Meter, LMR600 50 Ohms

1/2" 50 Ohm per Meter Low Loss Coaxial Cable, Solid Aluminum Center Conductor

• High-performance Times LMR coaxial cable.
• Superior design with high flexibility and low loss, recommended for a wide variety of applications requiring a low-loss, easy-to-install RF cable.

Advantages of LMR600 cable

• Performance similar to that offered by corrugated copper cables.
• Superior flexibility.
• Easier and faster installation.
• Better shielding and lower loss compared to other RG type cables.

Ideal for:

• Antenna installation.
• Installation of base stations on towers or masts.
• Jumpers for communication systems.
• Any application such as: radio communication systems, GPS, WiMax, Satellite, RF ID, DAS Systems, Etc.

Specs

• Impedance: 50 Ohm.
• Cable Outer Diameter: 14.99 mm
• Speed ​​Factor: 87%.
• Inner Conductor Diameter: 4.47 mm.(AWG 5.5).
• Center Conductor Material: Solid copper clad aluminum.
• Attenuation at 30 mts. at 450 MHz:  1.7 dB.
• Attenuation at 30 mts. at 800 MHz: 2.3 dB.
• Shielding: Tinned Copper Mesh + 100% Aluminum Laminated Tape
• Shielding Effectiveness: greater than 90 dB
• Dielectric Insulation: High Density Foamed Polyethylene.
• Minimum Bending Radius: 152.4 mm.
• Weight per meter: 0.2 Kg.
• Maximum Frequency: 6 GHz.
• Nominal Power : 1.3 kW at 450 MHz.
• Operating Temperature: -40 ºC to +85 ºC.

20 years of overseas service, Solid Copper-Clad Aluminum Center Conductor, Tinned Copper Braid
