CPE de Exterior de 5 GHz AC 867 Mbps, Antena direccional de 23 dBi, potencia de 29 dBm, PoE pasivo

5GHz AC 867Mbps Outdoor CPE, 23dBi Directional Antenna, 29dBm Power, Passive PoE

Sale price  $570,275 Regular price  $606,449
Skip to product information
CPE de Exterior de 5 GHz AC 867 Mbps, Antena direccional de 23 dBi, potencia de 29 dBm, PoE pasivo

5GHz AC 867Mbps Outdoor CPE, 23dBi Directional Antenna, 29dBm Power, Passive PoE

Sale price  $570,275 Regular price  $606,449
Shipping calculated at checkout.
Marca
TP-LINK
Referencia / SKU
CPE710
Disponibilidad
Agotado por ahora
Descripción y especificaciones

5GHz AC 867Mbps Outdoor CPE, 23dBi Directional Antenna, 29dBm Power, Passive PoE

HARDWARE FEATURES
Processor Qualcomm 750MHz CPU, MIPS 74Kc
Memory 128 MB DDR2 RAM, 16 MB Flash
Interface 1 10/100/1000 Mbps Shielded Ethernet Port (LAN/POE)
1 Reset Button
Power Supply Passive Power over Ethernet via LAN (+4.5pins; -7.8pins)
Voltage range: 16-27V DC
Dimensions 366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.)
Antenna Gain 23 dBi
Antenna Beamwidth 9° (Azimuth)/7° (Elevation)
Protection 15 KV ESD Protection
6 KV Lightning Protection
Housing Material: Plastic Exterior PC
Weatherproof: IP65 Waterproof and dustproof design
WIRELESS FEATURES
Wireless Standards IEEE 802.11a/n/ac
Wireless Speed Up to 867 Mbps (80 MHz, Dynamic)
Up to 400 Mbps (40 MHz, Dynamic)
Up to 173.4 Mbps (20 MHz, Dynamic)
Frequency 5.15~5.85 GHz
Transmission Power Max. 27 dBm (Adjustable power 1 dBm)
SOFTWARE FEATURES
Network Configuration WAN: Static / Dynamic / PPPoE
LAN: Static / Dynamic / DHCP
Forwarding: ALG / UPnP / Virtual Server / Port Trigger
Security: SPI Firewall / Ping Forbidden / DoS Protection
Access control
static routing
Bandwidth Control
IP and MAC Binding
Wireless Settings Selectable channel width: 20/40/80 MHz
Automatic channel selection
Transmission power control
Dynamic Frequency Selection (DFS)
WDS Enable/Disable
Security: WPA/WPA2 Encryption, WPA-PSK/WPA2-PSK (AES/TKIP),
SSID Broadcast Enable/Disable
Multi-SSID with VLAN tagging (AP mode only)
Distance/ACK Timeout Setting
wireless MAC address filter
Advanced Wireless:
Beacon Interval / RTS Threshold / Fragmentation Threshold / DTIM Interval / AP Isolation / Short GI / Wi-Fi Multimedia
Long-range PtP
Management Remote discovery and management via the Pharos Control app
HTTP/HTTPS web-based administration
System log
SNMP Agent (v2c)
Ping Watch Dog
Dynamic DDNS
SSH Server
System Tools Indicators: Signal strength / Noise / CCQ transmission / CPU / Memory
Monitors: Performance / Stations / Interfaces / ARP / Routes / WAN / DHCP
Spectrum analyzer
Speed ​​test
Whistle
Traceroute
Antenna alignment
System Level Optimizations Optimized IGMP Snooping / Proxy for multicast applications
POE ADAPTER FEATURES
Dimensions(W*D*H) 85.8×43.9×29.7 mm
Interfaces 1 AC outlet with ground protection
1 x 10/100/1000 Mbps Shielded Ethernet Port (Power + Data)
1 Port × 10/100/1000 Mbps Shielded Ethernet (Data)
Button Remote Reset Button
Power Status LEDs Green
Entrance 100-240VAC, 50/60Hz
Exit 24VDC, 0.5A Max
+4, 5 pins; -7, 8 pins. (Supports up to 60m Power over Ethernet)
Efficiency >84.29%
Certifications CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
OTHERS
Certifications CE, FCC, RoHS, IP65, IC
Package Contents Outdoor Wireless CPE
24V 0.5A PoE Passive PoE Adapter
Mast Mounting Kit
AC power cable
Installation Guide
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Note: We recommend using the following web browsers: Google Chrome, Safari, Firefox.
Environmental Factors Operating temperature: -40°C~70°C (-40℉~158℉)
Storage temperature: -40℃~70℃ (-40℉~158℉)
Operating humidity: 10%~90% non-condensing
Storage humidity: 5%~95% non-condensing
