OLT de 8 puertos EPON con 16 puertos Uplink (8 puertos Gigabit Ethernet + 4 puertos SFP + 4 puertos SFP+), hasta 512 ONUs

8-port EPON OLT with 16 Uplink ports (8 Gigabit Ethernet ports + 4 SFP ports + 4 SFP+ ports), up to 512 ONUs

$2,973,805 $3,905,550
Skip to product information
OLT de 8 puertos EPON con 16 puertos Uplink (8 puertos Gigabit Ethernet + 4 puertos SFP + 4 puertos SFP+), hasta 512 ONUs
  • OLT de 8 puertos EPON con 16 puertos Uplink (8 puertos Gigabit Ethernet + 4 puertos SFP + 4 puertos SFP+), hasta 512 ONUs
  • 8-port EPON OLT with 16 Uplink ports (8 Gigabit Ethernet ports + 4 SFP ports + 4 SFP+ ports), up to 512 ONUs
  • 8-port EPON OLT with 16 Uplink ports (8 Gigabit Ethernet ports + 4 SFP ports + 4 SFP+ ports), up to 512 ONUs
  • 8-port EPON OLT with 16 Uplink ports (8 Gigabit Ethernet ports + 4 SFP ports + 4 SFP+ ports), up to 512 ONUs
  • 8-port EPON OLT with 16 Uplink ports (8 Gigabit Ethernet ports + 4 SFP ports + 4 SFP+ ports), up to 512 ONUs
  • 8-port EPON OLT with 16 Uplink ports (8 Gigabit Ethernet ports + 4 SFP ports + 4 SFP+ ports), up to 512 ONUs
  • 8-port EPON OLT with 16 Uplink ports (8 Gigabit Ethernet ports + 4 SFP ports + 4 SFP+ ports), up to 512 ONUs
8-port EPON OLT with 16 Uplink ports (8 Gigabit Ethernet ports + 4 SFP ports + 4 SFP+ ports), up to 512 ONUs

8-port EPON OLT with 16 Uplink ports (8 Gigabit Ethernet ports + 4 SFP ports + 4 SFP+ ports), up to 512 ONUs

$2,973,805 $3,905,550
Shipping calculated at checkout.
Marca
V-SOL
Referencia / SKU
V1600-D8
Disponibilidad
61 unidades disponibles
Descripción y especificaciones

8-port EPON OLT with 16 Uplink ports (8 Gigabit Ethernet ports + 4 SFP ports + 4 SFP+ ports), up to 512 ONUs

  • The V1600D8 EPON OLT is a 1U, 19-inch rack-mountable product with L3 functionality developed by VSOL. It complies with IEEE802.3ah and China CTC 2.1/3.0 standards, allowing for flexible and efficient EPON network construction. It is intelligent, easy to deploy, high-performance, and environmentally friendly. It meets the performance and volume requirements of equipment in different environments, providing users with stable, efficient, and value-added network access services.

' 8-port EPON V-SOL OLT '

  • Up to 512 ONUs .
  • 8 Uplink RJ45 Gigabit ports.
  • 4 Uplink SFP+ 10 Gigabit ports.
  • 4 Gigabit SFP Uplink ports.
  • EPON PX20.
  • Triple Play.
  • Layer 3 functions.
  • Includes AC power supply.
  • Up to 4,096 Vlans.
  • Distance 20 Km on each PON port .
  • Local management software .
  • Remote management software .
  • Management from mobile APP .

Main features:
  • Dimensions: 442*320*43.6mm (length × width × height).
  • Applications: Data, Video Surveillance, IP Telephony, CATV.
  • Online ONU configuration and management.
  • Rackable.
  • Bandwidth per PON port: 1.25 Gbps symmetrical.
  • Supports QoS.
  • Wavelength: TX: 1490 nm & RX: 1310 nm.
  • User-friendly management of: EMS / Web / Telnet / CLI / SSH.
  • CLI command style similar to conventional manufacturers.
  • Management APP.
Physical and Electrical Characteristics:
  • Includes an AC power supply
  • AC: 90-240 Vac, 47/63 Hz
  • CD: 48 Vdc
  • Maximum consumption: 45W.
  • Weight: 4.3 Kg.
  • Operating temperature: -10 to 55° C.
Network Features:
  • Layer 3 and Layer 2 functions.
  • 8 EPON ports.
  • 8 Uplink RJ45 10/100/1000 Mbps ports.
  • 4 Uplink SFP+ 10000 Mbps ports.
  • 4 Uplink SFP 1000 Mbps ports.
  • 1 Auxiliary port.
  • 1 Console port.
  • EPON PX20+.
  • Receiving sensitivity: ≤-27dBm.
  • 9/125 μm SMF fiber type.
  • Division ratio 1:64.
  • Supports VLAN tag/Untag, VLAN transparent transmission, QinQ.
  • DHCP Server.
  • QOS based on port, VID, TOS and MAC address.
  • IGMP snooping.
  • Access control list.

  • Does not include PON modules.

FTTX network design.

    Up to 512 ONUs, Layer 3 Functions, Up to 1.25 Gbps Symmetrical per PON Port, Management via: CLI, SNMP, WEB and Telnet, 16 Uplink Ports, Management from Cellular APP
