V-SOL
Dual G/EPON ONU with 2.4 GHz Wi-Fi + 1 Gigabit LAN port + 1 Fast Ethernet LAN port, up to 300 Mbps via wireless
Dual G/EPON ONU with 2.4 GHz Wi-Fi + 1 Gigabit LAN port + 1 Fast Ethernet LAN port, up to 300 Mbps via wireless
Regular price
$106.210 COP
Regular price
$116.167 COP
Sale price
$106.210 COP
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Dual G/EPON ONU with 2.4 GHz Wi-Fi + 1 Gigabit LAN port + 1 Fast Ethernet LAN port, up to 300 Mbps via wireless
.png)
ONU EPON/GPON Wi-Fi 2.4 GHz
Up to ' 300 Mbps ' via Wi-Fi
- 1 RJ45 10/100 Port + 1 RJ45 10/100/1000 Port
- 1 SC/UPC PON port
- Supports EPON PX20 / GPON Class B+
- Optical receiving sensitivity: ≤-28dBm
- Distance of 20 km
- 2 external 5dBi antennas
- IEEE802.11b/g/n Wi-Fi standards
- Power: 17dBm
- MIME
- Local management software .
- Remote management software .
- Management from mobile APP .
Main features:
- 185mm × 120mm × 34mm （Length × width × height)
- Maximum consumption: ≤6W
- Management: WEB, Telnet, CLI and V-SOL OLT
- Multiple SSID
- Wavelength: Tx 1310 nm, Rx 1490 nm / Tx 1490 nm, Rx 1550 nm
Physical and Electrical Characteristics:
- Power supply 12 Vdc, 1 A ( Includes DC power supply ).
- 2 RJ45 ports
- Wi-Fi 2.4 GHz
- Operating temperature: -30 ℃ ～ + 50 ℃
- Storage temperature: -30℃ to +70℃
Network Features:
- 1 Gigabit Ethernet Port + 1 Fast Ethernet RJ45 Port
- Supports IGMP Snooping
- Supports VLAN Tag/Untag
- IPv4/IPv6
- Supports DHCP / PPPOE / Static IP
- Bridge mode or router mode
Application diagram
- 2.4 GHz WiFi, GEPON/EPON, 2 5 dBi Antennas, Up to 300 Mbps via WiFi, Mobile APP Management, Remote Management Software
500 in stock
MODELO: V2802-GW
View full details
