XP20B Infrared Photocell (Transmitter with Receiver) / 2easy BUS Connection / Range of up to 20 meters / Use in Vehicle Access Barriers and Motors

XP20B Infrared Photocell (Transmitter with Receiver) / 2easy BUS Connection / Range of up to 20 meters / Use in Vehicle Access Barriers and Motors

$500.595 COP
$547.526 COP $500.595 COP
Sale Sold out
Shipping calculated at checkout.

XP20B Infrared Photocell (Transmitter with Receiver) / 2easy BUS Connection / Range of up to 20 meters / Use in Vehicle Access Barriers and Motors

Main features:
  • Alignment Mode: Automatic
  • Technology: BUS 2easy
  • Nominal capacity: 20 m
  • Protection index: IP 54
Physical and Electrical Characteristics:
  • Power supply: BUS 2easy.
  • Consumption: Tx=10 mA, Rx=10 mA
  • Operating temperature: -20°C/+55°C
Highlighted Features:
  • Horizontal mechanical adjustment angle: -90° / +90°
  • Vertical optical self-alignment angle: ±7° (20m) ±13.5° (5m)
  • Compatibility only with control cards with BUS 2easy technology.

Simple alignment

Allows for up to 180° rotation adjustment on both the transmitter and receiver, making it faster and safer for difficult-to-align installations.

What does the XP20B model include?

  • 1 IR transmitter, requires connection to the 2easy BUS.
  • 1 IR receiver, requires connection to the 2easy BUS.

    Out of stock

    MODELO: 785103
