HIKVISION
Access Controller / 2 Doors / 4 Fingerprint and Card Readers / Video Integration / 100,000 Cards / Includes Cabinet and 12VDC/8A Power Supply / Supports Backup Battery
Access Controller / 2 Doors / 4 Fingerprint and Card Readers / Video Integration / 100,000 Cards / Includes Cabinet and 12VDC/8A Power Supply / Supports Backup Battery
Couldn't load pickup availability
Access Controller / 2 Doors / 4 Fingerprint and Card Readers / Video Integration / 100,000 Cards / Includes Cabinet and 12VDC/8A Power Supply / Supports Backup Battery
- Events: 300,000
- Cards: 100,000
- Footprints: 5,000
- Access Control by Time and Doors.
- Multi-User Verification.
- First card function.
- Super card and super password function.
Password: ✓ AntiPassback: ✓
Differences with DSK2602 (previous version): Supports ISUP5.0, ISAPI and OSDP protocols.
- - IVMS4200 Scope (data sheet)
- – HikCentral (via license).
- TCP/IP
- 4 Multi-Format Wiegand Input.
- 4 RS-485
- Metal Cabinet.
- Includes 12VDC / 8A power supply.
- 110 Vac power cable not included, suggested AC-CORD-1.8M.
- Supports backup battery (Recommended battery PL-4.5-12 NOT Included).
- Operating Temperature: -20 to 65 °C.
- Dimensions: 370 x 345 x 90 mm.
- 2 NC/NO/COM Relay Output For Sheet Metal.
- 2 Year Warranty.
- 4 Alarm inputs.
- 4 Auxiliary Relay Output NC/NO/COM.
- 2 inputs for REX button
- 2 door sensor inputs
- The controller also supports offline operation and is designed with tamper-proof switch.
The relays for the locks have 2 configurations:
- Dry or live contact.
- NO or NC (Jumper selectable).
HIKVISION access control panels support integration with cameras, DVRs and NVRs of the same brand through the free IVMS4200 software to have video evidence of events that occur in the access control system, for example when a door is opened, when a card is read correctly, when a door is forced or is left open, etc.
Only compatible with DS-K1201 series fingerprint reader.
Compatible card readers are listed in the optional accessories list (above).
Fingerprint and Card Reading
Hikvision DSK26XX series access control panels have direct integration with biometrics by using the DS-K1201 series biometric slaves, they comply with the IP65 standard which allows them to be installed even outdoors.
✓ Supports up to 2 slave readers per door.
✓ Fingerprint and card reading on the same device.
USB Enroller
The DS-K1F820F USB enroller is essential for the implementation of our biometric access control. It allows you to enroll user fingerprints directly into the IVMS4200 software and then synchronize them via the network to the controllers.
Card Readers / Passwords
DS-K1101-M (MIFARE card only ) or DS-K1101-MK ( card + password ) series readers are recommended for Hikvision DS-K26XX Series controllers.
They allow door control using 2 readers per door (Entry/Exit) and connection at a distance of up to 1200 meters in daisy chain.
USB Enroller
The USB reel DS-K1F100-D8E It is recommended for the implementation of our access control, enrolling the cards directly into the IVMS4200 software in a simpler way to subsequently synchronize them via the network to the controllers.
HIKVISION Magnetic Plate
Model: DS-K4H258S
Hikvision launches its own magnetic sheet model, allowing the entire solution to be seen under one brand.
– 600 lbs of force (280 Kg).
✓ CE certified.
✓ LED indicator
Z and L mounts (Required)
The 'Z' and 'L' mounts are required for the installation of the magnetic plates, they are purchased separately and the model is DS-K4H258-L/Z.
IVMS4200 Integration Demo
(Access + Assistance + CCTV + Video Intercoms)
- Easy installation, Wide compatibility
Out of stock
MODELO: DS-K2602T
