12 Megapixel (4K) NVR / Facial Recognition / 16 IP Channels / 4 Hard Drive Bays / False Alarm Filter / Human Body and Vehicle Detection

• Video compression: H.265+ / H.265 / H.264+ / H.264.
• Supports USB mouse to operate (included).
• Supports 4 HDDs up to 10 TB. (not included).
• Supports ANR technology with HIKVISION IP camera when the network is disconnected.
• Supports DDNS (Hik-Connect, DynDNS, No-IP, etc.).
• Supports Hik-Connect P2P ( https://appstore.hikvision.com/ ).
• Remote access via phone: Android, iPhone, iPad (Hik-Connect).
• Support for IE, Chrome (ietab) browsers.
• IVMS-4200 client software (free).

Processing capabilities and network functions:

• Input throughput: 320 Mbps.
• Output throughput: 256 Mbps.

• Dimensions: 445 × 400 × 71mm.
• Power supply: 100 to 240 VAC / 30 W.
• Operating temperature: -10°C to 55°C.
• Weight: 5 Kg without HDD.
• Warranty: 5 years.

Input/Output Interfaces:

• Independent HDMI and VGA output.
• Audio Input: 1 Channel.
• Audio Output: 1 Channel.
• Alarm Input: 16
• Alarm Output: 8
• Supports two-way audio (two-way audio).

Facial Recognition:

• We can store up to 32 bookcases.
• We can store up to 100,000 images (photos).
• 16 video channels with facial recognition.
• When the camera detects a face and matches it with a face in the database, we can: record, notify the software (iVMS-4200), send an email, activate an alarm output, etc.
• We recommend installing the IDS-2CD7 camera model to provide 16 video channels with facial recognition. Each camera allows for one channel with facial recognition.
• We can have up to 8 facial recognition channels if we handle cameras from the DS-2CD2XX3G0 / DS-2CD2XX3G2 / DS-2CD2XX5 / DS-2CD2XX7G2 series.

ACUSENSE (False Alarm Filter):

• With ACUSENSE technology we can avoid false alarms such as movement of trees, animals, etc.
• By activating ACUSENSE technology, it only detects the human body and vehicles to truly detect important events and thus eliminate false alarms.
• Supports up to 16 channels with ACUSENSE using cameras of maximum 2 Megapixel: DS-2CD2XX3G0 / DS-2CD2XX3G2 / DS-2CD2XX5.
• Supports up to 16 channels with ACUSENSE using cameras: DS-2CD3XX / DS-2CD2XX7G2 (which support ACUSENSE).

Note: Only facial recognition or ACUSENSE can be enabled (you cannot have both at the same time).
