• TurboHD 1080P Lite Ver. 4.0 Technology
• Technology support: HD-TVI / HD-CVI / AHD / Analog (CVBS).
• iVMS-4200 client software.
• Compatible with Hik-Connect P2P ( https://appstore.hikvision.com/ ).
• Support Hik-connect Domain/DynDNS/NO-IP service.
• Supports 16 TURBOHD / analog channels + 2 IP channels = 18 channels in total.
• NOTE: Allows you to turn off analog channels to add IP channels.
• The audio is received by the TVI signal
• It has AcuSense to filter humans and vehicles by motion detection (It does not have video analytics such as line crossings / area entry)

To connect the IP channels you need to use a POE switch (not included)

• Power supply: 12 Vdc.
• Power consumption without hard drive: 7 W.
• Operating temperature: -10 ºC to 55 ºC
• Dimensions: 285 × 210 × 45 mm (W × D × H)
• Weight: 1.8 Kg without hard drive.
• Note: Does not support channel zero.
• Does not support remote control
• Warranty: 2 years.

• Video input:
  • 16 channels (BNC, 1.0Vp-p, 75Ω).
• Video output:
  • HDMI/VGA: 1920×1080, 1280×1024, 1280×720, 1024×768.
• Audio input: 1 (RCA, 2.0 Vp-p, 1KΩ).
• 16 Audio inputs per coaxitron ( compatible models )
• Audio output: 1 (RCA, 2.0 Vp-p, 1KΩ).
• Alarm input: N/A
• Alarm output: N/A
• USB Interface: 2 port (2.0) rear.
• Network interface: 1 port (RJ-45 10/100 Mbps).
• HDD Capacity: 1 @ 10TB.

To use 2-way audio, it is recommended to place a microphone on the audio input; a camera with coaxitron audio is not recommended for 2-way audio.

• H.265+ / H.265 / H.264.
• HD-TVI: 1080P Lite@30 IPS.
• HD-CVI: 1080P Lite@30 IPS.
• CVBS: WD1@30 IPS.
• AHD: 1080P Lite@30IPS.
• IP: 5 Megapixel.
