Main Features:

• Compatible IEEE 802.3af (15W) and IEEE 802.3at (30W).
• Sixteen (16) ports for cameras/devices over ethernet
• Speed: 10/100/1000 Mbps
• Maximum power per port 30W
• Automatic detection and protection of pre-existing non-PoE cameras/devices
• Real-time energy diagnostics via email and alert notifications on the Windows dashboard.

Physical and Electrical Characteristics:

• 115VAC, 60Hz, 3A or 230VAC, 50Hz, 1.8A.
• The unit provides PoE/PoE+ 30W total power per port.
• Total power: 480W.
• Cable type: 4-pair CAT5e or structured cabling. Distance: up to 100m.
• Speed: 10/100/1000 BaseT, half/full duplex auto-negotiation.
• Dimensions (Length x Width x Height) 1.625” x 19.125” x 8.5” (41.3mm x 486mm x 216mm).
• Product weight: 4.05 lbs. (1.84 kg).
• Temperature: Operation -20ºC to 50ºC (-4ºF to 122ºF).
• Temperature: Storage -20º to 70ºC (-4ºF to 158ºF).
• Relative humidity: 85% +/-5%.
• Operating altitude: Up to 2,000m.
• BTU/Hr. (approx.): 245 BTU/Hr.

Highlighted Features:

• Remote network management allows for camera/device reboot and monitoring.
• Provides local and/or remote access to critical information via LAN/WAN.
• Report email notifications and real-time alerts on the Windows dashboard.
• Event log history.
• Illuminated main power disconnect circuit breaker with manual reset (breaker).
• Local and/or remote access to critical information via LAN/WAN.
• Incident log history.
• Built-in IP network manager, allows remote monitoring or reboot of the camera.
• Built-in battery charger.
• UL in the US and Canada.
• CE Approved
• Lifetime Warranty/ Made in the USA
