Main Features:

• Four ports (4) PoE/PoE+ (up to 30W) or two ports (2) Hi-PoE (60W)
• Compatible IEEE 802.3af (15W) and IEEE 802.3at (30W). 120W total power.
• One (1) Gigabit SFP Port
• Maximum power per port 30W
• NEMA4/4X enclosure, IP66 rating for outdoor use
• Charger included for sealed lead acid or gel batteries.
• Automatic switch to backup battery when AC fails.
• LED indicating PoE activity.
• Certification in the USA and Canada

Physical and Electrical Characteristics:

• 115VAC, 60Hz, 2.5A or 230VAC, 50/60Hz, 1.3A.
• Maximum Power: Four (4) PoE+ ports (30W) or two (2) Hi-PoE ports (60W). Compatible with IEEE 802.3af (15W) and IEEE 802.3at (30W). 120W total power.
• Fiber Port: One (1) Gigabit SFP Port.
• Cabinet Dimensions (L x W x H): 13.31” x 11.31” x 5.59” (338.1mm x 287.3mm x 142mm).
• NEMA 4/4X certified, IP66-11 enclosure for outdoor use.
• Product Weight: 10.32 lbs. (4.68 kg).
• Temperature: 120W Operation: -40ºC to 45ºC (-40ºF to 113ºF)
• Temperature: Storage -40ºC to 85ºC (-40ºF to 185ºF).
• Relative humidity: 85% +/-5%
• Operating altitude: Up to 2,000m.
• BTU/Hr. (approx.): 61 BTU/Hr.

Highlighted Features:

• CE approved.
• Lifetime Warranty / Made in the USA
• Remote network management allows you to reset and monitor your camera/device.
• Provides local and/or remote access to critical information via LAN/WAN.
• Email notifications and Windows Dashboard alerts provide real-time diagnostics.
• The event log tracks history
• LED Indicators: Individual LEDs for each PoE port.
  Individual IP link status, 10/100Base-T/active
  LEDs for The ALOS LED indicates the fiber connection for the SFP port.
  The pulse LED indicates the correct operation of the equipment.
