• CloudCore Router, CPU 72 Núcleos , 1 Puerto Gigabit Ethernet, 8 Puertos SFP/SFP+, 16 GB Memoria
1 2

MIKROTIK

CloudCore Router, 72-Core CPU, 1 Gigabit Ethernet Port, 8 SFP/SFP+ Ports, 16 GB Memory

CloudCore Router, 72-Core CPU, 1 Gigabit Ethernet Port, 8 SFP/SFP+ Ports, 16 GB Memory

$23.006.152 COP
$26.985.218 COP $23.006.152 COP
Sale Sold out
Shipping calculated at checkout.

CloudCore Router, 72-Core CPU, 1 Gigabit Ethernet Port, 8 SFP/SFP+ Ports, 16 GB Memory

CCR1072-1G-8S+

The flagship router, the CCR1072, is powered by a 72 -core Tilera CPU, each core clocked at 1GHz, and to fully utilize this power, the CCR1072 is equipped with eight independently connected 10G SFP+ ports.

The unit comes equipped with RouterOS L6 installation, 16GB of onboard ECC RAM, color LCD touchscreen, dual removable ( hotplug ) power supplies for redundancy, smart card slot, microUSB, full-size USB, microSD and 2x M.2 slots for additional storage.

Thanks to the single-core 72 processor and ports that are directly connected to the CPU, CCR1072 is capable of over 120 million packets per second of throughput.

Main features of RouterOS

Specifications

Details
Product code CCR1072-1G-8S+
Architecture TILE
CPU TLR4-07280
CPU core count 72
CPU nominal frequency 1 GHz
Dimensions 443x315x44mm
License level 6
Operating System RouterOS
Size of RAM 16 GB
Storage size 128 MB
Storage type NAND
Tested ambient temperature -20°C to 60°C

Powering

Details
Number of AC inputs 2
AC input range 100-240
Maximum power consumption 125 W

Ethernet

Details
10/100/1000 Ethernet ports 1

Fiber

Details
SFP+ ports 8

Peripherals

Details
Memory card type microSD, 2x M.2
Memory Cards 3
Serial port RJ45
Number of USB ports 2
USB Power Reset Forks
USB slot type microUSB type AB; USB type A
Max USB current (A) 1
Smart card slot Forks

Other

Details
CPU temperature monitor Forks
Current Monitor Forks
PCB temperature monitor Forks
Voltage Monitor Forks


Accessories Included:

Ethernet test results

CCR1072-1G-8S+ Tile 72 Core (1200Mhz, DDR1333) Max possible throughput
Mode Configuration 1518 bytes 512 bytes 64 bytes
kpps Mbps kpps Mbps kpps Mbps
Bridging none (fast path) 6,502.0 78,960.3 18,790.0 76,963.8 119,047.6 60,952.4
Bridging 25 bridge filter rules 6,130.5 74,448.8 8,192.7 33,557.3 10,339.5 5,293.8
Routing none (fast path) 6,502.0 78,960.3 18,790.0 76,963.8 86,507.0 44,291.6
Routing 25 simple queues 6,502.0 78,960.3 12,370.4 50,669.2 13,474.2 6,898.8
Routing 25 IP filter rules 4,667.6 56,683.3 5,985.1 24,515.0 5,873.8 3,007.4

  1. All tests are done with Xena Networks specialized test equipment (XenaBay), and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0.1% packet loss tolerance in 64, 512, 1518 byte packet sizes
  3. Values ​​in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
  4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

    Out of stock

    MODELO: CCR1072-1G-8S+
