ADVANCED LAYER 3 SWITCH, STACKABLE, 48 x 10/100/1000BASE-TX PoE+, 2 x SFP+, 2 x SFP+/Stack
Advanced Gigabit Layer 3 PoE+ Stackable Switch
A rugged solution that supports today's high-power devices.
Key Features
- 48 Gigabit ports with four 10 Gigabit uplinks
- Dual hot-swap power supplies
- Power over Ethernet provides the full 30 watts of PoE+ on all ports
- Long-distance stacking of up to 8 units supports distributed environments
Specs
| Product | 10/100/1000T copper ports (RJ-45) | SFP 100/1000X ports | 1/10 Gigabit SFP+ ports | 10 Gigabit stacking ports | Module slots | PoE-enabled ports | Change of fabric | Forwarding rate |
|---|---|---|---|---|---|---|---|---|
| x930-52GPX | 48 | - | 4 (2 if stacked) | 2* | 1 | 48 | 336 Gbps | 250 Mpps |
* Stacking ports can be configured as additional 1G/10G Ethernet ports when the unit is not stacked, or if the StackQS module is used
Physical
| Product | Width x Depth x Height | Mounting | Unpackaged weight | Packaged weight | Packed dimensions |
|---|---|---|---|---|---|
| x930-52GPX | 440 x 420 x 44 mm (17.32 x 16.54 x 1.73 inches) |
Rack mount | 5.2 kg (11.5 lb) | 7.2 kg (15.9 lb) | 56 x 53 x 15 cm (22.1 x 20.9 x 5.9 inches) |
Power and noise characteristics
| No PoE charging | Full PoE+ load (PWR800) | Full PoE+ load (PWR1200) | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Product | Maximum energy consumption | Maximum heat dissipation | Noise | Maximum energy consumption | Maximum heat dissipation | Noise | Maximum energy consumption | Maximum heat dissipation | Noise |
| x930-52GPX | 97 W | 330 BTU/h | 44.7 dBA | 577 W | 331 BTU/h | 45.8 dBA | 880 W | 341 BTU/h | 56.0 dBA |
Noise: Tested according to ISO7779; front passenger position
Power over Ethernet supply combinations
| Maximum PoE ports supported | ||||||
|---|---|---|---|---|---|---|
| Power supply installed | Available PoE power | Class 1 (4.0 W) | Class 2 (7.0 W) | Class 3 (15.4 W) | Class 4 (30W) | Maximum redundant PoE power |
| PWR800 | 380 W | 48 | 48 | 24 | 12 | - |
| PWR800 + PWR800 | 740 W | 48 | 48 | 48 | 24 | 380 W |
| PWR1200 | 740 W | 48 | 48 | 48 | 24 | - |
| PWR1200 + PWR1200 | 1440 W | 48 | 48 | 48 | 48 | |
Share
Out of stock
MODELO: AT-X930-52GPX-B91
