(CCR2004-1G-12S+2XS) Cloud Core Router 12 ports 10G SFP+, 2 25G SFP28, Redundant Source
(CCR2004-1G-12S+2XS) Cloud Core Router 12 ports 10G SFP+, 2 25G SFP28, Redundant Source
Couldn't load pickup availability
(CCR2004-1G-12S+2XS) Cloud Core Router 12 ports 10G SFP+, 2 25G SFP28, Redundant Source
The 'improvise. Adapt. Overcome.' mentality can be very useful, but sometimes you just need a device that works and solves the problem without additional tweaking. The CCR2004-1G-12S+ 2XS does exactly that: forget all the connectivity issues and expand your setup any way you want. This handy router features 12 x 10G SFP+ and 2 x 25G SFP28 ports.
CCR2004-1G-12S+2XS is our most powerful single-core router yet. It delivers incredible single-tunnel throughput (up to 3.4 Gbps) and BGP feed throughput.
Be ready for anything: 10G, 40G and now 25G! Together with MikroTik multiport products such as CRS317-1G-16S+RM, CRS312-4C+8XG-RM and CRS326-24S+2Q+RM your network setup will have no limits. Performance-wise CCR2004-1G-12S+2XS is on par with famous CCR1009/CCR1016 routers. And with dual redundant power supply you can forget about unexpected downtime! With its elaborate port configuration the new CCR2004-1G-12S+2XS is the perfect addition to any professional networking arsenal – it will save you tons of time in some tough situations! RAM size in RouterOS v6 1792MB ECC / RouterOS v7 4GB ECC
Specs
Details | |
---|---|
Product code | CCR2004-1G-12S + 2XS |
Architecture | ARM 64bit |
CPU | AL32400 |
CPU cores | 4 |
Nominal CPU frequency | 1700 MHz |
Dimensions | 443 x 224 x 44 mm |
License level | 6 |
Operating system | RouterOS |
RAM size | 4GB |
Storage size | 128 MB |
Storage type | NAND |
Room temperature tested | -20°C to 60°C |
Feeding
Details | |
---|---|
Number of AC inputs | 2 |
AC input range | 100-240 |
Maximum energy consumption | 49 W |
Maximum power consumption without accessories | 32 W |
Ethernet
Details | |
---|---|
10/100/1000 Ethernet ports | 1 |
Fiber
Details | |
---|---|
SFP+ ports | 12 |
Number of 25G SFP28 ports | 2 |
Peripherals
Details | |
---|---|
Serial port | RJ45 |
Other
Details | |
---|---|
CPU Temperature Monitor | Yeah |
PCB Temperature Monitor | Yeah |
Voltage monitor | Yeah |
Certifications and approvals
Details | |
---|---|
Certification | CE/RED, EAC, ROHS |
Parts included
-
2x IEC cables -
Screw and leg kit (K10) -
White rack mount bracket
- 64-bit ARM CPU, 4 Cores 1.7 GHz, 4 GB RAM, 12 SFP+ 10G Ports, 2 SFP28 25G Ports, 1 1G Ethernet Port, RouterOS 6 License Operating System, Power Supply: Redundant 100-240 Vac up to 49 W
Share
20 in stock
MODELO: CCR2004-1G-12S+2XS
