PTP Backhaul Radio, Integrated 8 dBi Antenna, 4X4 MIMO, 4.9 - 6.4 GHz, IP67, Speed ​​up to 1.5 Gbps, Automatic Adaptation to the Environment, Cloud Monitoring

PTP Backhaul Radio, Integrated 8 dBi Antenna, 4X4 MIMO, 4.9 - 6.4 GHz, IP67, Speed ​​up to 1.5 Gbps, Automatic Adaptation to the Environment, Cloud Monitoring

Ports:

1 10/100/1000 Mbps data port.

Modes of operation :

PTP:

• Access point.
• Season.

Characteristics :

Adjustable channel widths:

• PtP: single or dual 20/40/80 MHz

Outdoor ingress protection rating : IP67

Maximum performance:

• PTP 1.5 Gbps Aggregate IP UL/DL (1.7 Gbps PHY)

Security

• 128-bit AES PSK with hardware acceleration

Frequency range

• PTP: 4.9 to 6.4 GHz

Maximum output power :

• 30 dBm (2 chains)
• 27 dBm (4 chains)

Management services:

• Mimosa cloud monitoring and HTTPS handling of legacy SNMPv2 and Syslog monitoring

Physical and electrical characteristics:

• Passive PoE power 48 VDC or 802.3at
• Maximum power consumption: 20 W.

Dimensions :

• Height: 241 mm (9.5')
• Width: 139 mm (5.5')
• Depth: 76 mm (3.0')

Connector Type : Waveguide

Weight : 1.4 kg.

IP67 protection rating

Operating temperature : -40 to 55 °C.

Does not include PoE injector, add model POE50V or PoE 802.3at

Note : the equipment already includes an internal surge protector, it is recommended to land on a physical ground.

Integrated 8 dBi antenna
