• Convertidor de Medios de RS-232/ RS-422/ RS-485 a Fast Ethernet, Administración Web, SNMP y Telnet
1 3

PLANET

RS-232/RS-422/RS-485 to Fast Ethernet Media Converter, Web Management, SNMP, and Telnet

RS-232/RS-422/RS-485 to Fast Ethernet Media Converter, Web Management, SNMP, and Telnet

$458.469 COP
$552.888 COP $458.469 COP
Sale Sold out
Shipping calculated at checkout.

RS-232/RS-422/RS-485 to Fast Ethernet Media Converter, Web Management, SNMP, and Telnet



Common facilities



Video Surveillance

Process Control



 Access Control



Specs
Serial port 1 x DB9 male
Serial standards RS232 / RS422 / 4-wire RS485 / 2-wire RS485
Ethernet ports 1 x RJ45
Standard 10/100BASE-TX
Distance 100 m
Dimensions 97 x 70 x 26 mm
Weight 184 g
Energy requirements
External power adapter 5V DC, 2A max.
Energy consumption
5.5 Watts (max.)
Facility
Wall and DIN rail mounting kit (optional)
Management interfaces
Web Administration Administration of the
Telnet Administration console
from the Windows-based VCOM utility
SNMPv1, v2c / SNMP Trap
UNI-NMS Monitoring
PLANET Smart Discovery Utility
Mode of operation
â– TCP Server / TCP Client
â– UDP Client
â– Virtual COM
â– RFC2217
â– Telnet Server
â– Pair connection: remote (slave)
â– Pair connection: local (master)
â– Modbus conversion server/client
Platform supports
Based only on
Windows: Windows XP
Windows Server 2003
Windows 7
Windows Server 2008
Windows 8 (You must install the latest version of WinPcap)
Windows Server 2012 (You must install the latest version of WinPcap)
Windows 10
Operating temperature
-10 ~ 60 degrees C
Accessories included

1 x ICS110 Converter.

1 x User Manual

1 x Power supply.
    Includes 5 Vdc at 2 A voltage source, UNI-NMS management interface, Temperature support from -10 to 60°C

Out of stock

MODELO: ICS-110

View full details
