Fuel sensor for BLE 4.0 vehicle tracking / Wireless / Easy installation / 1000mm cuttable
Fuel sensor for BLE 4.0 vehicle tracking / Wireless / Easy installation / 1000mm cuttable
Couldn't load pickup availability
Fuel sensor for BLE 4.0 vehicle tracking / Wireless / Easy installation / 1000mm cuttable
Wireless fuel level sensor for vehicle tracking.
A giant leap into the future of wireless telematics.
Installing a fuel sensor has never been easier and faster with the TDBLE1000 sensor.
Traditional fuel sensor installation is time-consuming. Wireless communication eliminates the lengthy process of running cables throughout the vehicle. NO MORE CABLES!
Super fuel economy
Keeping control of fuel costs is essential for all companies.
Fuel tracking increases savings for the company and helps detect events such as fuel refueling, allowing them to determine if the declared amount is the same as the amount actually put into the tank.
Fuel discharge events help detect fuel theft or removal by providing live monitoring of the data processed by the sensor.
Technical characteristics
| Measurement error in the operating environment | No more than 1% |
| Operating mode | Digital |
| Digital mode - interface - data transmission protocol |
Bluetooth LE (BLE) Escort BLE |
| Range (under normal operating conditions without interference and obstacles with the use of the ESCORT receiver base) | up to 10 meters |
| Data exchange period with the database | 10 seconds |
| Receiver sensitivity / transmitter power | -96 dB / 0 dB |
| Degree of body protection according to GOST 14254 | IP69S |
| Protection against electric shock according to GOST 12.2.007.0 | Class III |
| Type of explosion protection | intrinsically safe electrical circuit of level 'ia' |
| Explosion protection marking | 0ExiаIIÐ' Т6 Ð¥ |
| Explosive operating mixture according to GOST R IEC 60079-20-1-2011 | categories IIA, IIB |
| Explosion protection zones according to GOST IEC 60079-10-1-2011 | 0; 1 and 2 |
| Operating conditions: - ambient temperature, °Ð¡ - limited ambient temperature, °C - atmospheric pressure, kPa - limited atmospheric pressure, kPa |
-45 - +50 -60 - +85 84 - 106.7 57 - 110 |
| Overall dimensions, max. mm | 90x90x(L+38), where L is the gauge length in mm |
| Nominal length of the meter | It is indicated on the label (attached) |
| Weight, max. kg | 0.5+0.4xL, where L-length of the meter in meters |
| Supply voltage, max. V | 3.6 |
.
Videos
46 in stock
MODELO: TDBLE1000
