• It allows you to disable analog TURBOHD channels and install IP cameras on all of them. You can install up to 6 IP cameras in total. For each analog TURBOHD channel that is disabled, an additional IP channel is generated.
• PENTAHYBRID recorder: HD-TVI / HD-CVI / Analog / IP / AHD.
• Multi-site client software up to 256 channels (iVMS-4200).
• Support Hik-Connect P2P/DynDNS/No-IP.
• Advanced Features: Line Crossing Detection & Intrusion Detection.
• Supports motion detection 2.0 (only triggers the event when it detects humans or vehicles).

Compression and resolution:

• Compression: H.265+ / H.265 / H.264+ / H.264.
• Supports 4 TURBOHD / analog channels + 2 IP channels = 6 channels in total.
• Supports 5 Technologies
  • TVI: 8MP @ 8IPS / 5MP @ 10IPS / 4MP @ 12IPS / 1080P - 720P @30IPS
  • AHD: 5MP @ 10IPS / 4MP @ 12IPS / 1080P - 720P @30IPS
  • CVI: 4MP @ 12IPS / 1080P - 720P @30IPS
  • CVBS: 30IPS
  • IP up to 8 Megapixel
• Note: The display on all channels will be in 8MP Real, but the grading only on channel 1 (BNC port) will be in 8MP Real, for channels 2, 3 and 4 the recording will be in 8MP Lite.

• Power supply: 12 Vdc (4-pin power supply included, 1.5 A)
• Power consumption without HDD: 10 watts.
• Operating temperature: -10 ºC to 55 ºC
• Dimensions: 315 x 242 x 45 mm
• Weight: 1.16 Kg without HDD.
• Hard drive not included
• Not compatible with remote control
• Warranty: 2 Years.

The DVR supports two video channels with human body detection or vehicle detection, allowing us to be more precise when recording and downloading any other type of movement.

It is necessary to consider which of the analytics will be used since it is not possible to use both at the same time.

• Human and Vehicle Filter Configuration Guide click here

• Multi-zone motion detection.
• Digital zoom in viewing and recording.
• Supports multiple recording types, including real-time, manual recording.
• Smart search for recordings by motion detection.
• SDK and demo codes are provided to reduce application development time.
• Recording with automatic overwriting.

Input/Output Interfaces:

• Video output in HDMI / VGA: 1920×1080, 1280×1024, 1280×720, 1024×768.
• BNC Video Output: 1 Channel (BNC, 1.0Vp-p, 75Ω), Maximum Resolution: 704 x 480.
• HDMI and VGA: simultaneous output.
• Supports audio on all its channels via coaxitron using cameras with integrated audio ( see compatible models ).
• Audio input: 1 (RCA, 2.0 Vp-p, 1KΩ).
• Audio output: 1 (RCA, 2.0 Vp-p, 1KΩ).
• Serial interface: RS-485 (HIKVISION C, COAXITRON, PELCO D, PELCO P, etc.).
• USB interface: 2 ports (2.0).
• Network interface: 1 port (RJ-45 10/100 Mbps).
• HDD Capacity: 1 @ 10 TB.

Devices with AcuSense can filter out up to 95% of false alarms, with the effectiveness of this filtering depending on the distance and viewing angle of the target and camera. Some pets and insects can trigger alerts based on this.
