MU-MIMO 8x8 Access Point, 5.1-6.4 GHz, Up to 7 Gbps Capacity, Integrated 24 dBi Antenna, 90º Opening Angle, Point-Multipoint, 2 SFP Ports and 1 Fast Ethernet Port.

MU-MIMO 8x8 Access Point, 5.1-6.4 GHz, Up to 7 Gbps Capacity, Integrated 24 dBi Antenna, 90º Opening Angle, Point-Multipoint, 2 SFP Ports and 1 Fast Ethernet Port.

Distances depend on site conditions such as spectrum availability, noise levels, full line of sight, and desired bandwidth.

Main features of the A6.

• Integrated GPS + GLONASS system for efficient synchronization of data packets in Tx and Rx.
• 10 Gbps Ethernet port
• 2 SFP Ports
• Advanced security: WAP3; AES; RADIUS; 802.1X.
• Up to one million packets per second .
• Maximum performance up to 7 Gbps aggregate speed in DL/UL.


Radio

• MIMO and modulation: 8X8 MU-MIMO OFDM, BPSK QAM.
• Channel width 20/40/80/160 MHz
• Maximum transmission power: 29 dBm.
• Low latency < 1 ms.
• For outdoor use: IP67.
• Temperature range: -40 to 55°C (-40 to 131°F)
• Frequency of 4.9 - 6.4 GHz

Physical and electrical characteristics

• Maximum power consumption: 40 W
• Passive POE power: 48-56 Vdc
• Passive PoE injector POE56V (Not-included).

Dimensions :

• Depth: 75 mm
• Width: 295 mm
• Height: 490 mm
• Weight : 3.95 kg (8.7 lbs)

Note : the equipment already includes an internal surge protector, it is recommended to land on a physical ground.

Supports monitoring via Mimosa Cloud.
