Symmetrical 45° Horn Sector Antenna, 15 dBi, 4.9 - 7GHz, Ideal for high noise environments, RPSMA connector type, with mounting and jumpers included

Symmetrical 45° Horn Sector Antenna, 15 dBi, 4.9 - 7GHz, Ideal for high noise environments, RPSMA connector type, with mounting and jumpers included

Technical Specifications

• Frequency range 4.9 to 7 GHz
• Gain 15 dBi
• VSWR <2.0
• Dual polarization (V/H ± 45°)
• Isolation >30 dB
• Front to back ratio >30 dB
• Horizontal beamwidth 45°
• Vertical beamwidth 45°
• Maximum power per port 50W
• Impedance 50 Ω
• INCLUDES JUMPERS from RPSMA to RPSMA

Mechanical Specifications

• RPSMA connector
• Antenna size 150 x 140 mm
• Weight 1 kg
• Operating temperature -40, +70 °C (-32 °F to +158 °F)
• Stainless steel screws, nuts and mounting.

Dual polarity (V/H ±45°), Super light, Non-existent side lobes, 45° beam width, includes RPSMA to RPSMA jumpers
